CGS - CARTRIDGE GREASE SEAL

The SEPCO® CGS is a single, cartridgemounted mechanical seal that can be used to replace double seals without using a water flush. The unique feature of the CGS Seal is a grease barrier cavity to prevent product leakage to the atmosphere without elaborate environmental controls.

OPERATING CAPABILITIES:
Pressures: 350 psig; 24 bar g
Temperatures: 32° to 250° F; 0° to 121° C
Speeds: 7500 fpm; 38 m/s

Cartridge Mounted
Easy installation • Facilitates impeller adjustments
No critical installation measurements
Versatile Design
Fits standard and over-sized stuffing boxes
Stationary Design
Eliminates misalignment
• Reduces wear High PV factors
Single Spring Design
Consistent face loads • Non-clogging
Internally Balanced
Reduced hydraulic load
Reduced power consumption
Automatic Grease Dispenser Option
Automatic operation
• Easy to install, inspect & refill
Low cost • Reduced surveillance & maintenance

• The Hydraload-B functions as a bearing block replaces packing rings in the stuffing box.
• The Hydraload-B utilizes the original equipment lantern ring for flushing.
• The system also can be used to increase mechanical seal performance in applications where shaft deflection results in premature mechanical seal failure.
• The Hydraload-B can be used flush less where clean fluids and gases are being sealed.

The SEPCO· Model SSF sealing liquid monitor is designed for applications where uninterrupted seal water flow is required. Adequate seal water flow for cooling and lubrication result in water savings, energy savings, reduced
maintenance, and extended life of seals. The SSF is compatible with all seal types. The sturdy modular construction and many accessories make it very flexible.
