Distillery Hose

Plicord Distillery 150

Application: Transfer of high proof alcohol and other liquids (ex. Whiskey, Vodka).
Construction:
   Tube: UHMWPE (FDA/USDA and 3A compliant, NSF 61 listed material)
   Cover: Corrugated Grey EPDM (wrapped impression)
   Reinforcement: Spiral-plied fabrics with double galvanized wire helix Max.

CoMax. Alcohol Concentrate: 100% per volume
Temperature Range: -40°F to 150°F (-40°C to 66°C)
Order Code: 549-683)
Branding: CONTINENTAL CONTITECH PLICORD DISTILLERY 150 PSI WP FDA 3-A & USDA ##### MADE IN CANADA (3/4" Spiral Transfer Tape, White Backing with Green Lettering)

SAP	Size	ID		OD		W.P.		Bend Radius		Vaccum HG		Weight
	in	in	mm	in	mm	psi	MPa	in	mm	in	mm	lb/ft	kg/m
20866181	1	1	25.4	1.449	36.8	150	1.03	4	102	29	737	0.57	0.854
20866182	1 1/2	1.5	38.1	1.984	50.4	150	1.03	5	127	29	737	0.87	1.288
20866183	2	2	50.8	2.531	64.3	150	1.03	6	152	29	737	1.2	1.789
20866184	3	3	76.2	3.557	90.4	150	1.03	9	229	29	737	1.93	2.877
20866185	4	4	101.6	4.582	116.4	150	1.03	12	305	29	737	2.63	3.920
