SUPERCOIL· is Self-Storing Air Hose made from 95 Durometer Polyurethane. This extremely flexible hose is perfect for applications where kink and abrasion resistance are important considerations. Our contemporary looking state-of-the-art strain relief system protects the hose al its weakest point (at the barb) while enhancing the appearance of the entire assembly. other manufacturers use a strain relief that limits the ability of the hose to bend but ours was uniquely designed to take advantage of Polyurethane's flexibility, giving the user a much wider range of motion without the possibility of kinking. Reusable compression filtings are available for quick and easy installation without the need of any special tools. Supercoi" Hose Assemblies can be ordered with these reusable compression fittings already installed for rough environments that may require more frequent repairs. We also offer rigid fittings for additional durability on high impact or severe vibration applications.
|
Specifications:
• Temperature Range: - 40 F to + 165 F (- 40 C to + 74 C)
• Working Pressure: Varies By Hose Size (see Ordering
Information Chart on page 4 for specific information)
• Maximum Recommended Working length: 90% of
Material length
• Hose Sizes: 3/16" I. D. to 1/2" I. D.
• Standard Colors: Black., Blue, Neon Orange, Red,
Transparent Blue & Yellow
Features:
• SUPER flexible - 100% kink proof
• Rugged brass swivel fittings provide long life & minimal flow restrictions
• State-of-the-art strain relief system protects the hose & increases its maneuverability
• Also available with reusable fittings for quick and easy repairs
• All swivel fittings indude reusable thread sealant preapplied at the factory
• low tension retractability - minimizes user fatigue
• Abrasion resistant
• Soft Polyurethane material will not mar finishes
• Strong enough to repel most oils and chemicals
• 16" tail on the working (tool) end eliminates tangling of the tool with the coils
• 8" tail on the supply end makes the connection to the air source easy
• More durable and lighter weight than rubber hose - easy to handle
|
