Nylon tubing is a popular choice for low pressure pneumatic applications because of its combination of flexibility and
toughness. Nycoil uses a heat and fight stabilized, very flexible high grade Nylon 12 compound that yields the finest quality tubing available. Some of the qualities of tubing extruded from Nylon 12 raw material are good chemical
resistance, low water absorption and superior dimensional stability. Nylon is the most recommended tubing material
for all types of pneumatic circuits. A circuit designer could never get into trouble using Nylon tubing for pneumatic circuits. Due to its physical properties, Nylon is the number one choice for reliable connections with all types of fittings. Nylon retains its performance integrity in elevated temperatures and generally, because of it's higher pressure and temperature characteristics, Nylon will have a greater flow passage than composite tubing made from other material with the same outside diameter. These factors should never be overlooked when designing pneumatic circuits.
Temperature Range: -40°F to +200°F (-40°C to +93°C)
|
