Notice
This information is provided for reference only!
The product(s) represented in this literature were previously manufactured by Goodyear Engineered Products- Veyance Technologies until January of 2015 when this legal entity was acquired by Continental AG of Germany and became part of their ContiTech Industrial Products Division. Many of these products are still available today but are currently branded with the Continental ContiTech logo and name. Some product names have been changed, however most have remained the same under Continental.
Goodyear Rubber Products, Inc. is an independent authorized distributor of Continental ContiTech products.
|
APPLICATION: Designed as a lightweight and flexible hose to transfer biodiesel and ethanol blends, gasoline and other petroleum products under pressure, gravity flow or medium suction (up to 23" Hg) at ambient temperature. Maximum aromatic content 60%. Outer PVC helix provides abrasion resistance and low coefficient of friction. With Antistatic wire (low resistance).
CONSTRUCTION TUBE: Black Nitrile synthetic rubber (static dissipating)
COVER: Black Chemivic® synthetic rubber with Orange Pliovic® outer helix
REINFORCEMENT: Synthetic fabric plies
TEMPERATURE: - 40°F to 160°F (- 40°C to 71°C)
PACKAGING: 100' lengths, coiled and bagel pack
BRANDING: Example: Goodyear Paladin Drop Hose (Date Code) Made in Canada.
COUPLINGS: Use Goodyear’s Insta-Lock Cam & Groove
|
