Product Notes:
• Take blade width and ordering number from the worn blade and use the Replacement Blade Chart.
• For optimal cleaning and reduced blade retensioning maintenance, the cleaner blade width should be sized to fit the material path of the belt.
The material path is typically 2/3 of the belt width. In most cases a blade size of belt width minus 8" (200mm) may be the best selection.
• The ConShear
™
blade has a faceted profile that renews the cleaning edge as it wears.
• Visual tension check. No guesswork on blade tensioning. Simply measure the spring, check label on tensioner and turn adjusting
nut to restore optimal tension.
• ConShear blades are made of a special long-wearing urethane.
• A molded-in blade wear line indicates when the blade is worn out and needs to be replaced.
• Blade replacement is quick. Pull one pin, remove the old blade and slide the new one in.
U.S. Patent No. D482,508S
ConShear
™
Replacement Blades
EZP1
Standard Duty Precleaner
Blade Width Selection
BELT WIDTH
BELT WIDTH
- 2" (50mm)
BELT WIDTH
- 8" (200mm)
BELT WIDTH
- 14" (350mm)
in.
mm in.
mm in.
mm in.
mm
12 300
10
250 N/A N/A N/A N/A
18 450
16
400
10
250 N/A N/A
24 600
22
550
16
400
10
250
30 750
28
700
22
550
16
400
36 900
34
850
28
700
22
550
42 1050 40 1000 34
850
28
700
48 1200 46 1150 40 1000 34
850
54 1350 52 1300 46 1150 40 1000
60 1500 58 1450 52 1300 46 1150
72 1800 70 1600 64 1600 58 1450
P R O D U C T H A N D B O O K
Replacement ConShear
™
Blades
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
10
250
CRB10
75628
4.6
16
400
CRB16
75629
7.3
22
550
CRB22
75630 10.1
28
700
CRB28
75631 12.8
34
850
CRB34
75632 15.5
40
1000
CRB40
75633 18.3
46
1150
CRB46
75634 21.0
52
1300
CRB52
75635 23.8
58
1450
CRB58
75636 26.5
64
1600
CRB64
75775 29.2
70
1750
CRB70
75773 32.0
76
1900
CRB76
76940
34.7
82
2050
CRB82
76941
37.5
Other blade sizes available upon request.
Lead time: 1 working day
Replacement
High Temp ConShear
™
Blades
(Color Identification: Yellow)
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
10
250
CRB-HT10
76593
4.8
16
400
CRB-HT16
76594
7.6
22
550
CRB-HT22
76595 10.4
28
700
CRB-HT28
76596 13.2
34
850
CRB-HT34
76597 16.2
40
1000
CRB-HT40
76598 19.1
46
1150
CRB-HT46
76599 21.9
52
1300
CRB-HT52
76600 24.8
58
1450
CRB-HT58
76601 27.6
64
1600
CRB-HT64
76602 30.5
70
1750
CRB-HT70
76603 33.4
Lead time: 1 working day
Replacement White ConShear
™
Blades
(Chemical Resistant/Food Grade)
‡
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
10
250
CRB-W10
78471
4.8
16
400
CRB-W16
78472
7.6
22
550
CRB-W22
78473
10.4
28
700
CRB-W28
78474
13.2
34
850
CRB-W34
78475
16.2
40
1000
CRB-W40
78476
19.1
46
1150
CRB-W46
78477
21.9
52
1300
CRB-W52
78478
24.8
58
1450
CRB-W58
78479
27.6
64
1600
CRB-W64
78480
30.5
70
1750
CRB-W70
78481
33.4
Lead time: 1 working day
‡ All ingredients used in the urethane formulation of this blade comply with the
relevant requirements of 21 CFR (FDA Code of Federal Regulations) for use in
repeated bulk dry food applications
