26
ConShear
™
LS
Replacement Blades
EZP-LS
Limited Space Precleaner
Product Notes:
• Take blade width and ordering number from the worn blade and use the Replacement Blade Chart.
• For optimal cleaning and reduced blade retensioning maintenance, the cleaner blade width should
be sized to fit the material path of the belt. The material path is typically 2/3 of the belt width.
• The ConShear
™
blade has a faceted profile that renews the cleaning edge as it wears.
• Visual tension check. No guesswork on blade tensioning. Simply measure the spring,
check label on tensioner and turn adjusting nut to restore optimal tension.
• ConShear blades are made of a special long-wearing urethane.
• A molded-in blade wear line indicates when the blade is worn out and needs to be replaced.
• Blade replacement is quick. Pull one pin, remove the old blade and slide the new one in.
U.S. Patent No. D482,508S (blade)
Patent Pending (tensioner)
Blade Width Selection
BELT WIDTH
BELT WIDTH
- 2" (50mm)
BELT WIDTH
- 8" (200mm)
BELT WIDTH
- 14" (350mm)
in.
mm in.
mm in.
mm in.
mm
12 300
10
250 N/A N/A N/A N/A
18 450
16
400
10
250 N/A N/A
24 600
22
550
16
400
10
250
30 750
28
700
22
550
16
400
36 900
34
850
28
700
22
550
42 1050 40 1000 34
850
28
700
48 1200 46 1150 40 1000 34
850
54 1350 52 1300 46 1150 40 1000
60 1500 58 1450 52 1300 46 1150
P R O D U C T H A N D B O O K
Replacement ConShear
™
-LS Blades
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
10
250
CRB-LS10
77088 2.1
16
400
CRB-LS16
77089
3.3
22
550
CRB-LS22
77090
4.6
28
700
CRB-LS28
77091
5.8
34
850
CRB-LS34
77092
7.1
40
1000
CRB-LS40
77093
8.3
46
1150
CRB-LS46
77094
9.6
52
1300
CRB-LS52
77095 10.8
58
1450
CRB-LS58
77096 12.1
Other blade sizes available upon request.
Lead time: 1 working day
Replacement ConShear
™
-LS White
Blades
(Chemical Resistant/Food Grade)
‡
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
10
250
CRB-LS10W 77097
2.1
16
400
CRB-LS16W 77098
3.3
22
550
CRB-LS22W 77099
4.6
28
700
CRB-LS28W 77100
5.8
34
850
CRB-LS34W 77101
7.1
40
1000
CRB-LS40W 77102
8.3
46
1150
CRB-LS46W 77103
9.6
52
1300
CRB-LS52W 77104 10.8
58
1450
CRB-LS58W 77105 12.1
Other blade sizes available upon request.
Lead time: 1 working day
Replacement ConShear
™
-LS
High-Temp Blades
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
10
250 CRB-LS10HT 77551 2.1
16
400 CRB-LS16HT 77552
3.3
22
550 CRB-LS22HT 77553
4.6
28
700 CRB-LS28HT 77554
5.8
34
850 CRB-LS34HT 77555
7.1
40
1000 CRB-LS40HT 77556
8.3
46
1150 CRB-LS46HT 77557
9.6
52
1300 CRB-LS52HT 77558 10.8
58
1450 CRB-LS58HT 77559 12.1
Other blade sizes available upon request.
Lead time: 1 working day
‡ All ingredients used in the urethane formulation of this blade comply with the
relevant requirements of 21 CFR (FDA Code of Federal Regulations) for use in
repeated bulk dry food applications
