Belt Width Minus 2" (50mm)
Belt Width Minus 8" (200mm)
Match blade width to belt’s material path
Material Path
Belt Width
Blade Width
Material Path
Blade Width
Belt Width
Product Ordering
Information
EZP-LS
Limited Space Precleaner
Product Notes:
• For optimal cleaning and reduced blade retensioning maintenance, the cleaner blade width should be sized to fit the
material path of the belt. The material path is typically 2/3 of the belt width.
• Each cleaner can be retrofitted with three replacement blade sizes (belt width minus 2" (50mm), minus 8" (200mm), or
minus 14" (350mm).
• Comes complete with universal mounting plates and tensioner.
• Visual tension check. No guesswork on blade tensioning. Simply measure the spring, check label on tensioner and
turn adjusting nut to restore optimal tension.
• Visual blade wear check. Tensioner has built-in gauge to monitor blade wear.
• Works with mechanical splices. Urethane blade glides over splices.
• Compatible with reversing belts.
• For applications requiring longer pole lengths, go to the minus 8" (200mm) chart and select the cleaner one
belt width size larger. This will provide a pole 6" (150mm) longer and a blade size of belt width minus 2" (50mm).
U.S. Patent No. D482,508S (blade)
Patent Pending (tensioner)
P R O D U C T H A N D B O O K
EZP-LS Precleaner
Belt Width Minus 2" (50mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
12
300
10
250
EZP-LS212 77127 24.8
18
450
16
400
EZP-LS218 77128 28.2
24
600
22
550
EZP-LS224 77129 31.7
30
750
28
700
EZP-LS230 77130 35.1
36
900
34
850
EZP-LS236 77131 38.6
42
1050
40
1000 EZP-LS242 77132 42.0
48
1200
46
1150 EZP-LS248 77133 45.5
54
1350
52
1300 EZP-LS254 77134 48.9
60
1500
58
1450 EZP-LS260 77135 52.5
Lead time: 1 working day
EZP-LS Precleaner
Belt Width Minus 8" (200mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
18
450
10
250
EZP-LS818 77136 27.0
24
600
16
400
EZP-LS824 77137 30.4
30
750
22
550
EZP-LS830 77138 33.9
36
900
28
700
EZP-LS836 77139 37.3
42
1050
34
850
EZP-LS842 77140 40.8
48
1200
40
1000 EZP-LS848 77141 44.2
54
1350
46
1150 EZP-LS854 77142 47.7
60
1500
52
1300 EZP-LS860 77143 51.2
Lead time: 1 working day
