Page Background www.flexco.com

• phone: 1-630-971-0150

27

Specifications:

• Maximum Belt Speed....................................................... 500 FPM (2.5M/sec)

• Temperature Rating (ConShear, ConShear White)...... -30°F to 180°F (-35°C to 82°C)

• Temperature Rating (ConShear High Temp)................. Up to 275°F (135°C) with spikes to

............................................................................................. 325°F (164°C)

• Minimum Pulley Diameter ............................................... 6" (150mm)

• Blade Height ...................................................................... 4.5" (115mm)

• Usable Blade Wear Length ............................................. 2-3/8" (60mm)

• Blade Material................................................................... Urethane (proprietary blend for

............................................................................................. abrasion resistance and long wear)

• Available for Belt Widths................................................. 12" to 60" (300 to 1500mm).

Specifications

& Guidelines

EZP-LS

Limited Space Precleaner

Measure spring

length only (do not

include bushings)

Spring Length Chart

EZP-LS w/Purple or Yellow Blade

BLADE

WIDTH

PURPLE

SPRING

WHITE

SPRING

SILVER

SPRING

in.

mm in.

mm in.

mm in.

mm

10 250 2 51 N/A N/A N/A N/A

16 400 1 5/8 48 2 1/8 54 N/A N/A

22 550 N/A N/A 2

51 N/A N/A

28 700 N/A N/A 1 7/8 48 N/A N/A

34 850 N/A N/A 1 3/4 44 N/A N/A

40 1000 N/A N/A 1 1/2 38 N/A N/A

46 1150 N/A N/A 1 3/8 35

2

51

52 1300 N/A N/A N/A N/A 2

51

58 1450 N/A N/A N/A N/A 1 7/8 48

Shading indicates preferred spring option

Vertical

Horizontal

Pole Location Specs

A = Pulley Diameter + Lagging and Belt

C = Critical Spec to move location if necessary

X

A

C

Y

Pole Length

*

Max Conveyor Span

Move Dim. C

on arc

Pole Location Chart -

Imperial

A

X

Y

C

6"

2 5/8"

5 1/2"

6 1/8"

7"

3 1/4"

5 1/2"

6 3/8"

8"

3 7/8"

5 1/2"

6 3/4"

9"

4 3/8"

5 1/2"

7"

10"

5"

5 1/2"

7 3/8"

11"

5 1/2"

5 1/2"

7 3/4"

12"

6 1/8"

5 1/2"

8 1/4"

13"

6 5/8"

5 1/2"

8 5/8"

14"

7 1/8"

5 1/2"

9"

15"

7 5/8"

5 1/2"

9 3/8"

16"

8 1/4"

5 1/2"

9 7/8"

17"

8 3/4"

5 1/2"

10 3/8"

18"

9 1/4"

5 1/2"

10 3/4"

19"

9 3/4"

5 1/2"

11 1/4"

20"

10 1/4"

5 1/2"

11 5/8"

21"

10 3/4"

5 1/2"

12 1/8"

22"

11 1/4"

5 1/2"

12 1/2"

Pole Location Chart - Metric

A

X

Y

C

150

65

140

150

175

81

140

155

200

96

140

162

225

109

140

171

250

125

140

179

275

138

140

189

300

153

140

198

325

166

140

209

350

178

140

219

375

191

140

229

400

206

140

239

425

219

140

252

450

231

140

263

475

244

140

273

500

256

140

284

525

269

140

295

550

281

140

307

Pole Length Specifications

CLEANER

SIZE

POLE

LENGTH

MAXIMUM

CONVEYOR

SPAN

in.

mm in.

mm in.

mm

12 300 42 1050 37 925

18 450 48 1200 43 1075

24 600 54 1350 49 1225

30 750 60 1500 55 1375

36 900 66 1650 61 1525

42 1050 72 1800 67 1675

48 1200 78 1950 73 1825

54 1350 88 2200 83 2075

60 1500 94 2350 89 2225

Pole Diameter - 1-7/8" (48 mm)

Clearance Guidelines

for Installation

HORIZONTAL

CLEARANCE REQUIRED

VERTICAL

CLEARANCE REQUIRED

in.

mm

in.

mm

3

75

6 1/2

165

*Each pole size can be used with a blade size either belt

width minus 2" (50mm), belt width minus 8" (200mm), or

belt width minus 14" (350mm).

P R O D U C T H A N D B O O K
