18
U.S. Patent No. D482,508S
2
4
1
3
10
7
6
5
Detail view
of Item 10
7a
8
8a
9
(hidden)
8b
11
12
12a
14
13
Optional Spring Tensioner
Replacement
Parts List
EZP1
Standard Duty Precleaner
Spring Tensioner Selection Chart
CLEANER BLADE WIDTH
76403
EST-P
76404
EST-S
76405
EST-B
ConShear 12" - 28" (300 - 700mm)
X
ConShear 34" - 52" (850 - 1300mm)
X
ConShear 58" - 70" (1450 - 1750mm)
X
P R O D U C T H A N D B O O K
Replacement Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
12" (300mm) Pole
EZP1P12 75619 17.4
18" (450mm) Pole
EZP1P18 75620 20.3
24" (600mm) Pole
EZP1P24 75621 22.7
30" (750mm) Pole
EZP1P30 75622 26.5
36" (900mm) Pole
EZP1P36 75623 30.4
42" (1050mm) Pole
EZP1P42 75624 32.7
48" (1200mm) Pole
EZP1P48 75625 35.3
54" (1350mm) Pole
EZP1P54 75626 39.2
60" (1500mm) Pole
EZP1P60 75627 43.3
72" (1800mm) Pole
EZP1P72 75772 48.2
2 Mounting Plate Kit* (2 ea.)
EZP1MPK 75637 7.7
3 Torque Arm Kit* (1 ea.)
ESTAK-EST 76406 3.6
4 Pivot Shaft Bracket Kit* (1 ea.)
ESPSBK 76407 1.8
5 Pivot Block Kit*
ESPBK 76408 0.7
6 Pivot Rod Kit*
ESPRK 76409 1.2
7 Bushing Kit - Purple and Silver
(includes 2 bushings)
ESBK-PS 76410 0.1
7a Bushing Kit - Black
(includes 2 bushings)
ESBK-B 76411 0.1
8 Tension Spring - Purple
QMTS-P 75845 1.0
8a Tension Spring - Silver
ESS-S 76412 1.2
8b Tension Spring - Black
ESS-B 76413 1.4
9 Pole Lock* (1 ea.)
EZP1PL
75641 1.1
–
EST Tensioner - Purple*
for blade widths 12" - 28" (300 - 700mm)
(includes 1 each items 3, 4, 5, 6, 7 & 8)
EST-P 76403 7.7
–
EST Tensioner - Silver*
for blade widths 34" - 52" (850 - 1300mm)
(includes 1 each items 3, 4, 5, 6, 7 & 8a)
EST-S 76404 7.9
–
EST Tensioner - Black*
for blade widths 58" - 70" (1450 - 1750mm)
(includes 1 each items 3, 4, 5, 6, 7a& 8b)
EST-B 76405 8.1
10 Blade Pin (1 ea.)
EZP1BP 75642 0.1
*Hardware Included
Lead time: 1 working day
Optional Spring Tensioner & Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
11 Tension Arm Kit* (1 ea.)
HAR-K 78786
6.0
12 Tension Spring (1 ea.)
for sizes 12" - 30" (300 - 750mm)
STTS
74419
1.4
12a HD Tension Spring (1 ea.)
for sizes 36" - 72" (900 - 1800mm)
HDTS
74502
2.0
13 Spring Tension J-Bolt Mount (1 ea.)
STJM 74775
3.0
14 J-Bolt Kit* (1 ea.)
STJK
74417
0.7
– Optional Spring Tensioner Kit*
for sizes 12" - 30" (300 - 750mm)
EZP1OTK1 76418 11.2
– Optional Spring Tensioner Kit*
for sizes 36" - 72" (900 - 1800mm)
EZP1OTK2 76419 11.8
* Hardware Included
Lead time: 1 working day
