U.S. Patent No. D482,508S
*
*Each pole size can be used with a blade size either belt width minus 2" (50mm),
belt width minus 8" (200mm), or belt width minus 14" (350mm).
Top of
washer to top
of torque arm
Vertical
Horizontal
Max Conveyor Span
Pole Length
Specifications
& Guidelines
EZP1 & EZP1T
Standard Duty Precleaners
Clearance Guidelines for
Installation
HORIZONTAL
CLEARANCE
REQUIRED
VERTICAL
CLEARANCE
REQUIRED
in.
mm in.
mm
4
100
9 1/2
238
Pole Length Specifications
CLEANER SIZE
POLE LENGTH
MAXIMUM
CONVEYOR SPAN
in.
mm in.
mm in.
mm
12
300
42
1050
37
925
18
450
48
1200
43
1075
24
600
54
1350
49
1225
30
750
60
1500
55
1375
36
900
66
1650
61
1525
42
1050
72
1800
67
1675
48
1200
78
1950
73
1825
54
1350
88
2200
83
2075
60
1500
94
2350
89
2225
72
1800
106
2650
101
2525
Pole Diameter - 2-3/8" (60mm)
Spring Length Chart
with EST Spring Tensioner
BLADE
WIDTH
PURPLE
SPRING
SILVER
SPRING
BLACK
SPRING
in.
mm in.
mm in.
mm in.
mm
10 250 5 3/4 146 6 1/4 159 N/A N/A
16 400 5 1/4 133 6 152 N/A N/A
22 550 4 3/4 121 5 7/8 149 N/A N/A
28 700 4 1/4 108 5 5/8 143 N/A N/A
34 850 N/A N/A 5 3/8 137 5 5/8 143
40 1000 N/A N/A 5 1/8 130 5 1/2 140
46 1150 N/A N/A 5 127 5 1/4 133
52 1300 N/A N/A 4 3/4 121 5 1/8 130
58 1450 N/A N/A N/A N/A 5
127
64 1600 N/A N/A N/A N/A 4 3/4 121
70 1750 N/A N/A N/A N/A 4 5/8 117
Shading indicates preferred spring option
Twist Tensioner Chart
BLADE
WIDTH STANDARD HEAVY
DUTY
in.
mm
10"
250
8
6
16"
400
13
9
22"
550
18
12
28"
700
23
16
34"
850
27
19
40"
1000
32
23
46"
1150
37
26
52"
1300
N/A
29
58"
1450
N/A
33
64"
1600
N/A
36
70” 1750
N/A
40
