Belt Width Minus 2" (50mm)
Belt Width Minus 8" (200mm)
Match blade width to belt’s material path
Material Path
Belt Width
Blade Width
Material Path
Blade Width
Belt Width
Product Ordering
Information
EZP-LS Stainless Steel
Limited Space Precleaner
with White ConShear
™
LS Blade
Product Notes:
• White food-grade ConShear Precleaner is chemical resistant and all ingredients used in urethane formulation comply with the
relevant requirements of 21 CFR (FDA Code of Federal Regulations) for use in repeated bulk dry food applications.
• For optimal cleaning and reduced blade retensioning maintenance, the cleaner blade width should be sized to fit the material
path of the belt. The material path is typically 2/3 of the belt width.
• Each cleaner can be retrofitted with three replacement blade sizes (belt width -2" (50mm), -8" (200mm), or -14" (350mm)).
• Comes complete with universal mounting plates and tensioner(s).
• Visual tension check. No guesswork on blade tensioning. Simply measure the spring, check label on tensioner and turn
adjusting nut to restore optimal tension.
• Visual blade wear check. Tensioner has built-in gauge to monitor blade wear.
• Works with mechanical splices. Urethane blade glides over splices.
• Compatible with reversing belts.
• For applications requiring longer pole lengths, go to the minus 8" (200mm) chart and select the cleaner one belt width size larger.
This will provide a pole 6" (150mm) longer and a blade size of belt width minus 2" (50mm).
U.S. Patent No. D482,508S (blade)
Patent Pending (tensioner)
P R O D U C T H A N D B O O K
EZP-LS Stainless Steel Precleaner
with White ConShear
™
LS Blade
Belt Width Minus 2" (50mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
12
300
10
250
CLSFG-212 77144 24.8
18
450
16
400
CLSFG-218 77145 28.2
24
600
22
550
CLSFG-224 77146 31.7
30
750
28
700
CLSFG-230 77147 35.1
36
900
34
850
CLSFG-236 77148 38.6
42
1050
40
1000 CLSFG-242 77149 42.0
48
1200
46
1150 CLSFG-248 77150 45.5
54
1350
52
1300 CLSFG-254 77151 48.9
60
1500
58
1450 CLSFG-260 77152 52.5
Lead time: 1 working day
EZP-LS Stainless Steel Precleaner
with White ConShear
™
LS Blade
Belt Width Minus 8" (200mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
18
450
10
250
CLSFG-818 77153 27.0
24
600
16
400
CLSFG-824 77154 30.4
30
750
22
550
CLSFG-830 77155 33.9
36
900
28
700
CLSFG-836 77156 37.3
42
1050
34
850
CLSFG-842 77157 40.8
48
1200
40
1000 CLSFG-848 77158 44.2
54
1350
46
1150 CLSFG-854 77159 47.7
60
1500
52
1300 CLSFG-860 77160 51.2
Lead time: 1 working day
