U.S. Patent No. D482,508S
Product Notes:
• Recommended for standard-duty conveyor applications. For tougher belt applications see the MMP Medium-Duty Precleaner
(page 39). For extreme, abusive applications see the MHP Heavy-Duty Precleaner (page 47) or the MHCP Heavy-Duty
Cartridge Precleaner (page 54).
• Material Path Option: Fit the blade width to the belt’s material path. The material path is typically the center 2/3 of the belt width. In
most cases a blade size of belt width minus 8" (200mm) may be the best solution.
• Each cleaner pole is retrofittable for three blade sizes (belt width minus 2" (50mm), minus 8" (200mm) or minus 14" (350mm)).
• Pole Length: Belt width plus 54" (1350mm). For conveyors requiring longer pole lengths, go to the minus 8" (200mm) chart and select
the cleaner one belt width size larger. This will provide a pole 6" (150mm) longer and a blade size of belt width minus 2" (50mm).
For longer requirements see Installation Accessories - Pole Extender Kit (page 123).
• Visual Tension Check: No guesswork on blade tensioning. Measure the spring and adjust to specified length per blade width to
restore optimal tensioning.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
Belt Width Minus 2" (50mm)
Belt Width Minus 8" (200mm)
Material Path
Belt Width
Blade Width
Match blade width to belt's material path
Material Path
Belt Width
Blade Width
Product Ordering
Information
MSP
Standard Mine-Duty Precleaner
P R O D U C T H A N D B O O K
MSP Standard-Duty Precleaner
Belt Width Minus 2" (50mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
24
600
22
550
MSP-224
75787 83.4
30
750
28
700
MSP-230
75788 89.6
36
900
34
850
MSP-236
75789 98.2
42
1050
40
1000
MSP-242
75790 106.0
48
1200
46
1150
MSP-248
75791 113.2
54
1350
52
1300
MSP-254
75792 120.0
60
1500
58
1450
MSP-260
75793 125.7
72
1800
70
1750
MSP-272
75794 140.2
84
2100
82
2050
MSP-284
76796 164.2
Lead time: 1 working day
MSP Standard-Duty Precleaner
Belt Width Minus 8" (200mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
24
600
16
400
MSP-824
75795 80.6
30
750
22
550
MSP-830
75796 86.9
36
900
28
700
MSP-836
75797 95.5
42
1050
34
850
MSP-842
75798 103.2
48
1200
40
1000
MSP-848
75799 110.5
54
1350
46
1150
MSP-854
75800 117.2
60
1500
52
1300
MSP-860
75801 123.0
72
1800
64
1600
MSP-872
75802 134.7
84
2100
76
1900
MSP-884
76797 160.0
Lead time: 1 working day
