Product Ordering
Information
Stainless Steel MSP
Standard Mine-Duty Precleaner
U.S. Patent No. D482,508S
Product Notes:
• Recommended for standard-duty conveyor applications, but in corrosive environments.
• Material Path Option: Fit the blade width to the belt’s material path. The material path is typically the center 2/3 of the belt width.
In most cases a blade size of belt width minus 8" (200mm) may be the best solution.
• Each cleaner pole is retrofittable for three blade sizes (belt width minus 2" (50mm), minus 8" (200mm) or minus 14" (350mm)).
• Pole Length: Belt width plus 54" (1350mm). For conveyors requiring longer pole lengths, go to the minus 8" chart and select the
cleaner one belt width size larger. This will provide a pole 6" (150mm) longer and a blade size of belt width minus 2" (50mm).
For longer requirements see Installation Accessories - Pole Extender Kit (page 123).
• Visual Tension Check: No guesswork on blade tensioning. Measure the spring and adjust to specified length per blade width to
restore optimal tensioning.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
Material Path
Belt Width
Blade Width
Match blade width to belt's material path
Material Path
Belt Width
Blade Width
Belt Width Minus 2" (50mm)
Belt Width Minus 8" (200mm)
P R O D U C T H A N D B O O K
Stainless Steel MSP Standard-Duty Precleaner
Belt Width Minus 2" (50mm)
BELT WIDTH
BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
24
600
22
550
MSP-224-S/S 77453 83.4
30
750
28
700
MSP-230-S/S 77454 89.6
36
900
34
850
MSP-236-S/S 77455 98.2
42
1050
40
1000
MSP-242-S/S 77456 106.0
48
1200
46
1150
MSP-248-S/S 77457 113.2
54
1350
52
1300
MSP-254-S/S 77458 120.0
60
1500
58
1450
MSP-260-S/S 77459 125.7
72
1800
70
1750
MSP-272-S/S 77460 140.2
84
2100
82
2050
MSP-284-S/S 77461 164.2
Lead time: 3 weeks
Stainless Steel MSP Standard-Duty Precleaner
Belt Width Minus 8" (200mm)
BELT WIDTH
BLADE WIDTH
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
24
600
16
400
MSP-824-S/S 77462 80.6
30
750
22
550
MSP-830-S/S 77463 86.9
36
900
28
700
MSP-836-S/S 77464 95.5
42
1050
34
850
MSP-842-S/S 77465 103.2
48
1200
40
1000
MSP-848-S/S 77466 110.5
54
1350
46
1150
MSP-854-S/S 77467 117.2
60
1500
52
1300
MSP-860-S/S 77468 123.0
72
1800
64
1600
MSP-872-S/S 77470 134.7
84
2100
76
1900
MSP-884-S/S 77471 160.0
Lead time: 3 weeks
