U.S. Patent No. D482,508S
Match blade width to belt’s material path
Material Path
Belt Width
Blade Width
Material Path
Blade Width
Belt Width
Product Ordering
Information
EZP1
Standard Duty Precleaner
Product Notes:
• For optimal cleaning and reduced blade retensioning maintenance, the cleaner blade width should be sized to fit the
material path of the belt. The material path is typically 2/3 of the belt width. In most cases a blade size of belt width minus
8” (200mm) may be the best selection.
• Each cleaner can be retrofitted with three replacement blade sizes (belt width minus 2” (50mm), minus 8” (200mm), or
minus 14” (350mm)).
• Comes complete with universal mounting plates and tensioner.
• Visual tension check. No guesswork on blade tensioning. Simply measure the spring, check label on tensioner and turn
adjusting nut to restore optimal tension.
• Works with mechanical splices. Urethane blade glides over splices.
• Compatible with reversing belts.
• For applications requiring longer pole lengths, go to the minus 8” (200mm) chart and select the cleaner one belt width size
larger. This will provide a pole 6" (150mm) longer and a blade size of belt width minus 2” (50mm).
Belt Width Minus 2" (50mm)
Belt Width Minus 8" (200mm)
P R O D U C T H A N D B O O K
EZP1 Precleaner
Belt Width Minus 2" (50mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
12
300
10
250
EZP1-212
75610 49.4
18
450
16
400
EZP1-218
75611 55.3
24
600
22
550
EZP1-224
75612 61.2
30
750
28
700
EZP1-230
75613 67.1
36
900
34
850
EZP1-236
75614 73.0
42
1050
40
1000
EZP1-242
75615 78.9
48
1200
46
1150
EZP1-248
75616 84.8
54
1350
52
1300
EZP1-254
75617 90.7
60
1500
58
1450
EZP1-260
75618 96.6
72
1800
70
1750
EZP1-272
75771 102.5
Lead time: 1 working day
EZP1 Precleaner
Belt Width Minus 8" (200mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
12
300
–
–
N/A
N/A –
18
450
10
250
EZP1-818
75779 51.3
24
600
16
400
EZP1-824
75780 57.2
30
750
22
550
EZP1-830
75781 63.1
36
900
28
700
EZP1-836
75782 69.0
42
1050
34
850
EZP1-842
75783 74.9
48
1200
40
1000
EZP1-848
75784 80.8
54
1350
46
1150
EZP1-854
75785 86.7
60
1500
52
1300
EZP1-860
75786 92.6
72
1800
64
1600
EZP1-872
75774 98.5
Lead time: 1 working day
