U.S. Patent No. D482,508S
Match blade width to belt’s material path
Material Path
Belt Width
Blade Width
Material Path
Blade Width
Belt Width
Product Ordering
Information
EZP1T
TwistTensioner Precleaner
Product Notes:
• For optimal cleaning and reduced blade retensioning maintenance, the cleaner blade width should be sized to fit the
material path of the belt. The material path is typically 2/3 of the belt width. In most cases a blade size of belt width
minus 8” (200mm) may be the best selection.
• Each cleaner can be retrofitted with three replacement blade sizes (belt width minus 2” (50mm), minus 8” (200mm),
or minus 14” (350mm)).
• Comes complete with universal mounting plates and tensioner.
• Visual tension check. No guesswork on blade tensioning. Simply measure the spring, check label on tensioner and
turn adjusting nut to restore optimal tension.
• Works with mechanical splices. Urethane blade glides over splices.
• Compatible with reversing belts.
• For applications requiring longer pole lengths, go to the minus 8” (200mm) chart and select the cleaner one
belt width size larger. This will provide a pole 6" (150mm) longer and a blade size of belt width minus 2” (50mm).
Belt Width Minus 2” (50mm)
Belt Width Minus 8” (200mm)
P R O D U C T H A N D B O O K
EZP1T Precleaner with Twist Tensioner
Belt Width Minus 2" (50mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
12
300
10
250
EZP1T-212 78488 38.5
18
450
16
400
EZP1T-218 78489 44.5
24
600
22
550
EZP1T-224 78490 50.5
30
750
28
700
EZP1T-230 78491 56.5
36
900
34
850
EZP1T-236 78492 62.5
42
1050
40
1000
EZP1T-242 78493 68.4
48
1200
46
1150
EZP1T-248 78494 74.4
54
1350
52
1300
EZP1T-254 78495 83.7
60
1500
58
1450
EZP1T-260 78496 92.0
72
1800
70
1750
EZP1T-272 78497 101.6
Lead time: 1 working day
EZP1T Precleaner with Twist Tensioner
Belt Width Minus 8" (200mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm in.
mm
12
300
–
–
N/A
N/A –
18
450
10
250
EZP1T-818 78498 41.8
24
600
16
400
EZP1T-824 78499 47.8
30
750
22
550
EZP1T-830 78500 53.8
36
900
28
700
EZP1T-836 78501 59.8
42
1050
34
850
EZP1T-842 78502 65.8
48
1200
40
1000
EZP1T-848 78503 71.7
54
1350
46
1150
EZP1T-854 78504 78.5
60
1500
52
1300
EZP1T-860 78505 87.0
72
1800
64
1600
EZP1T-872 78506 98.9
Lead time: 1 working day
