120
Specifications
& Guidelines
Motorized Brush Cleaner
Specifications
19-1/2” (495mm)
9-5/8” (244mm)
9-5/8” (244mm)
1-1/2” (38mm)
12” (300mm)
5-1/2”
(140mm)
18-1/2” (470mm)
7” (178mm)
7” (178mm)
1 HP
2 HP
Belt Speed
Up to 700 fpm
(3.5M/sec)
Vertical and
Horizontal Clearance 12" (305mm)
Temperature Range -20ºF to 180ºF
(-30ºC to 82ºC)
Maximum Chevron or
Cleat Height
1/2" (13mm)
Bristle Length
3-1/4" (83mm)
Overall Diameter
12" (305mm)
Shaft Length
Belt Width plus 36" (915mm)
Shaft Diameter
1-1/2" (38mm)
Motor HP
1 HP (cleaners 18-42”
(450-1050mm)
2 HP (cleaners 48-84”
(1200-2100mm)
Motor voltage
208-230/460VAC 3 Phase*
*Other motors available upon request
