Product Ordering
Information
Motorized Brush Cleaner
Motorized Brush Cleaner
Product Notes:
• Spins opposite the belt direction for optimal cleaning.
• Uniquely patterned bristles aid in reducing material buildup and clogging.
• Adjustable tensioners allow easy brush-to-belt adjustment as the bristles wear.
• Works on mechanically spliced or vulcanized belts.
P R O D U C T H A N D B O O K
Motorized Brush Cleaner
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm
18 450 MBC-18 79494 136.7
24 600 MBC-24 79495 146.5
30 750 MBC-30 79496 150.2
36 900 MBC-36 79497 156.5
42 1050 MBC-42 79498 162.6
48 1200 MBC-48 79499 179.0
54 1350 MBC-54 79500 185.9
60 1500 MBC-60 79501 192.0
72 1800 MBC-72 79502 205.1
84 2100 MBC-84 79503 217.5
Replacement Brushes
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm
18 450 MBRD-18 79514 9.6
24 600 MBRD-24 79515 13.5
30 750 MBRD-30 79516 17.1
36 900 MBRD-36 79517 20.5
42 1050 MBRD-42 79518 23.7
48 1200 MBRD-48 79519 26.8
54 1350 MBRD-54 79520 30.7
60 1500 MBRD-60 79521 33.9
72 1800 MBRD-72 79522 41.0
84 2100 MBRD-84 79523 47.5
Optional Mounting
Brackets (Pair)
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
MBCDBK 79536 28.9
