U.S. Patent No. D482,508S
Pole Length Specifications*
Specifications:
• Maximum Belt Speed.....................................................1000 FPM (5M/sec)
• Temperature Rating ........................................................-30°F to 180°F (-35°C to 82°C)
• Usable Blade Wear Length ...........................................4-1/2" (113mm)
• Blade Height ....................................................................7-1/4" (185mm)
• Blade.................................................................................Urethane with UHMWadditive (softer durometer to squeegee water off
...........................................................................................and additive to enhance blade life)
• Available for Belt Widths...............................................24" to 96" (600 to 2400 mm)
...........................................................................................Other sizes available upon request.
*For special extra long pole length requirements a Pole Extender Kit (#76024) is available that
provides 30" (750mm) of extended pole length. (page 123).
Pole Diameter - 2-7/8" (73mm)
Spring Length Chart
with SST Spring Tensioner
Overall Pole Length
Maximum Conveyor Span
Clearance Guidelines
for Installation
Vertical
Horizontal
Shading indicates preferred spring option
Specifications
& Guidelines
MDWS
Secondary Cleaner
DryWipe for Removing Water
HORIZONTAL
CLEARANCE
REQUIRED
VERTICAL
CLEARANCE
REQUIRED
in.
mm in.
mm
4
100
10
250
BLADE
WIDTH
WHITE
SPRING
SILVER
SPRING
BLACK
SPRING
GOLD
SPRING
24"
3 1/8"
3 7/8"
N/A
N/A
30"
2 7/8"
3 3/4"
N/A
N/A
36"
N/A 3 3/4"
3 7/8"
N/A
42"
N/A 3 5/8"
3 3/4"
N/A
48"
N/A 3 1/2"
3 5/8"
N/A
54"
N/A 3 3/8"
3 5/8"
N/A
60"
N/A 3 1/4"
3 1/2"
N/A
72"
N/A
N/A 3 3/8"
3 5/8"
84"
N/A
N/A
3"
3 1/2"
96"
N/A
N/A
N/A 3 3/8"
CLEANER SIZE
BLADE WIDTH POLE LENGTH
MAXIMUM
CONVEYOR SPAN
in.
mm in.
mm in.
mm in.
mm
24
600
28
700
84
2100
68
1700
30
750
34
850
90
2250
74
1850
36
900
40
1000
96
2400
80
2000
42
1050
46
1150
102
2550
86
2150
48
1200
52
1300
108
2700
92
2300
54
1350
58
1450
114
2850
98
2450
60
1500
64
1600
120
3000
104
2600
72
1800
76
1900
126
3150
116
2900
84
2100
88
2200
138
3450
128
3200
96"
2400
100
2500
150
3750
140
3500
Top of Washer to
Mounting Base
PAT Pressure Chart
BLADE WIDTH PSI
18"
15#
24"
19#
30"
23#
36"
27#
42"
31#
48"
35#
54"
39#
60"
43#
72"
51#
84"
59#
96"
67#
