Product Ordering
Information Inspection Door
1a 1b
1c 1d
4
3
2
P R O D U C T H A N D B O O K
*Hardware included
*Hardware included
Replacement Parts
REF DESCRIPTION ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1a Inspection Door Screen 12 x 12 (300x300mm)* IDSC-1212 79311 1.9
1b Inspection Door Screen 12 x 18 (300x450mm)* IDSC-1218 79312 2.5
1c Inspection Door Screen 18 x 24 (450x600mm)* IDSC-1824 79313 4.4
1d Inspection Door Screen 24 x 24 (600x600mm)* IDSC-2424 79314 5.5
2 Replacement Seal - 5’ (1.5M)** IDSEAL 79315 0.1
3 Replacement Hinge IDHINGE 79316 0.2
4 Replacement Latch (incl. bolt, bushings & nut) IDLATCH 79317 2.5
**One 5’ length of seal is needed for 12x12” and 12x18” doors or screens, and two 5’ lengths are needed for 18x24”
and 24x24” doors or screens. Double if replacing seal on both door and screen.
Inspection Doors
DESCRIPTION ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
Inspection Door 12 x 12 (300x300mm)* INDR-1212 79303 19.2
Inspection Door 12 x 18 (300x450mm)* INDR-1218 79304 23.5
Inspection Door 18 x 24 (450x600mm)* INDR-1824 79305 35.2
Inspection Door 24 x 24 (600x600mm)* INDR-2424 79306 42.8
Inspection Door w/Screen 12 x 12 (300x300mm)* INDR-1212S 79307 21.2
Inspection Door w/Screen 12 x 18 (300x450mm)* INDR-1218S 79308 26.0
Inspection Door w/Screen 18 x 24 (450x600mm)* INDR-1824S 79309 39.7
Inspection Door w/Screen 24 x 24 (600x600mm)* INDR-2424S 79310 48.3
