123
Optional Mounting Kits
(includes 2 brackets/bars)
*Hardware Included
Lead time: 1 working day
OPTIONAL MOUNTING KITS FOR BELT CLEANERS
Versatile, adjustable brackets and plates that can be mounted on the conveyor structure so
precleaners and secondary cleaners can be easily and quickly bolted into place.
Provides 30" (750mm) of extended pole length.
Lead time: 1 working day
Pole Extender Kit
(includes 2 pole extenders)
75830
Optional Mounting Bar Kit
(with bolts, nuts and washers)
• For mounting precleaners on open head pulleys.
• Weld on both sides of pulley and bolt on steel plates.
• For use with MSP, MMP, MHP, MHCP
76073
Optional Top Angle Kit
• Used with both
standard and long
mounting bracket kits
for additional mounting
options.
76537
Mounting Plate Kit (incl. 2 plates, 16" x 32"
(400 x 800 mm))
• For use with Mounting Bars to mount
cleaners on open head pulleys.
• For use with MSP, MMP, MHP, MHCP
Specs and Notes:
• Standard brackets are 13" W x 15-1/2" L (330x394mm).
• Long brackets are 13" W x 21-1/2" L (330x546mm).
• Mounting bars are 1-1/2" W x 16" L (38x400mm) with
(4) 5/8-11 tapped holes.
• Mounting plates are 16" W x 32" L (400x800mm) with
(4) 5/8" (16mm) holes.
Optional
Mounting Kits
Installation Accessories
76071
Standard Mounting
Bracket Kit
• For most secondary
cleaner installs.
79434
MST Drop Bracket Kit
• For installs of
secondary cleaners
with MST tensioners.
76072
Long Mounting
Bracket Kit
• For installations
that require extra
length legs.
79536
Brush Cleaner Drop
Bracket Kit
• For brush cleaner
installations that require
extra length legs.
P R O D U C T H A N D B O O K
DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
Standard Mounting Bracket Kit *
SSTSMB 76071
34.3
Long Mounting Bracket Kit *
SSTLMB 76072
43.5
Optional Top Angle Kit *
SSTOTA 76073
10.5
Optional Mounting Bar Kit *
MMBK
75830
19.5
Mounting Plate Kit (incl. 2 plates)
MMPK
76537 140.0
MST Drop Bracket Kit
MSTDB 79434
27.7
MBC Drop Bracket Kit
MBCDBK 79536
28.9
DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
2-7/8" Pole Extender Kit
MAPEK 76024 21.9
2-3/8" Pole Extender Kit
RAPEK 77423 18.0
