U.S. Patent No. D482,508S
MDWS Secondary Belt Cleaner
MDWS Secondary Belt Cleaner
with SAT2 Tensioner
Product Notes:
• The ConShear
™
“DryWipe” (DW) Blade is excellent for removing water from the belt. Use as the final cleaner in a cleaning system.
• Actual blade width is belt width plus 4" (100mm). The extra length ensures the water is removed from the belt.
• Pole Length: Belt width plus 60" (1500mm) for cleaners up to 60" (1500mm), belt width plus 54" (1350mm) for cleaners over 60"
(1500mm). For longer requirements, see Accessories - Pole Extender Kit (page 123).
• Visual Blade Tension Check: Measure the tension spring and refer to the Spring Length Chart on mounting base for the correct
length for best cleaning performance.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
Lead time: 1 working day
Lead time: 1 working day
Replacement ConShear
™
DW Blades
(Color Identification: Black)
Product Ordering
Information
MDWS
Secondary Cleaner
DryWipe for Removing Water
Actual blade width is belt width + 4".
ConShear DW Blades are black for easy identification.
Lead time: 1 working day
P R O D U C T H A N D B O O K
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
MDWS-24
75868 115.1
30
750
MDWS-30
75869 122.8
36
900
MDWS-36
75870 127.8
42
1050
MDWS-42
75871 138.3
48
1200
MDWS-48
75872 146.8
54
1350
MDWS-54
75873 154.5
60
1500
MDWS-60
75874 162.2
72
1800
MDWS-72
75875 177.7
84
2100
MDWS-84
76806 193.2
96
2400
MDWS-96
79063 208.7
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
CDWB24
75884
12.8
30
750
CDWB30
75885
15.5
36
900
CDWB36
75886
18.3
42
1050
CDWB42
75887
21.0
48
1200
CDWB48
75888
23.8
54
1350
CDWB54
75889
26.5
60
1500
CDWB60
75890
29.2
72
1800
CDWB72
75891
34.7
84
2100
CDWB84
76942
40.5
96
2400
CDWB96
79062
46.3
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600 MDWS-24P 78745 115.1
30
750 MDWS-30P 78746 122.8
36
900 MDWS-36P 78747 127.8
42
1050 MDWS-42P 78748 138.3
48
1200 MDWS-48P 78749 146.8
54
1350 MDWS-54P 78750 154.5
60
1500 MDWS-60P 78751 162.2
72
1800 MDWS-72P 78752 177.7
84
2100 MDWS-84P 78753 193.2
96
2400 MDWS-96P 79064 208.7
