Product Ordering
Information
DRX750
Impact Beds
DRX750
Lead time: 2 weeks
Lead time: 2 weeks
Replacement Parts
Lead time: 1 working day
Replacement Bars, Bar Supports and Bolt Kits
Required per Belt Width - DRX750
Impact Bed Size
Cema C or D,
5" IDLERS
CEMA C or D,
6" IDLERS
DRX750: 24"- 36"
Shim idler up 1/2"
No Kits Required
DRX750: 42"- 72"
No Kits Required Use (1) SHIM-KITM;
Shim up 0.5"
Impact Bed Size
CEMA E,
6" IDLERS
CEMA E,
7" IDLERS
DRX750: 36"-60"
Use (3) SHIM-KITM;
Shim up 1.5"
Use (4) SHIM-KITM;
Shim up 2"
DRX750: 72"
Use (4) SHIM-KITM;
Shim up 2"
Use (5) SHIM-KITM;
Shim up 2.5"
in.
24 30 36 42 48 54 60 72
mm
600 750 900 1050 1200 1350 1500 1800
Slider Bars Required
2
2
2
2
2
2
2
2
Impact Bars Required
4
4
5
7
8 10 11 12
Impact Bar Supports Required
4
4
5
7
8 10 11 12
Impact Bar Bolt Kits Required
26 26 31 41 46 56 61 66
* Belt width + 9" = Structure width
U.S. Patent No. 7,815,040
5
1
2
6
7
1a
2a
3
4
4a
CEMA D construction
(hidden)
P R O D U C T H A N D B O O K
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1 Impact Bar, 4'
IB4
76926 17.0
1a Impact Bar, 5'
IB5
76927 21.2
2 Slider Bar, 4' (1.2M)
SB4
78789 20.0
2a Slider Bar, 5' (1.5M)
SB5
78790 24.1
3
Impact Bar Bolt Kit (
incl. (1) ea 5/8"
carriage bolt, square washer, flat washer,
lock washer, Nylock nut)
IBBK 76928 0.5
4
Impact Bar Support -M 4'
(incl. (1) bar
support, (2) ea carriage bolt,
square washer, lock washer, Nylock nut)
IBS-M4 76931 16.9
4a
Impact Bar Support -M 5' (
incl. (1)
bar support, (2) ea carriage bolt, square
washer, lock washer, Nylock nut)
IBS-M5 76932 21.2
5 Sliding Support Arm Bolt Kit
(incl. (2)
2" bolts, (2) lock washers, (2) Nylock nuts)
ISABK-LMH 77529 2.0
6 Isolation Mount Kit
IMK
76936 3.8
7 DRX750 Shim Kit
(incl. 6 shims)
SHIM-KITM 77549 20.4
BELT WIDTH TONNAGE
RATING
(ton/hr)
4' (1.2 M) BEDS, 20
°
TROUGH
4' (1.2 M) BEDS, 35
°
TROUGH
in.
mm
ORDERING
NUMBER
ITEM
CODE
WT.
LBS
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
24
600
8,100
DRXM-24-420 76848 365.0
DRXM-24-435 76864 365.0
30
750
8,100
DRXM-30-420 76849 397.0
DRXM-30-435 76865 397.0
36
900
9,500
DRXM-36-420 76850 467.0
DRXM-36-435 76866 467.0
42
1050
12,200
DRXM-42-420 76851 592.0
DRXM-42-435 76867 592.0
48
1200
13,600
DRXM-48-420 76852 623.0
DRXM-48-435 76868 623.0
54
1350
16,300
DRXM-54-420 76853 704.0
DRXM-54-435 76869 704.0
60
1500
17,600
DRXM-60-420 76854 779.0
DRXM-60-435 76870 779.0
72
1800
19,000
DRXM-72-420 76855 896.0
DRXM-72-435 76871 896.0
BELT WIDTH TONNAGE
RATING
(ton/hr)
5' (1.5 M) BEDS, 20
°
TROUGH
5' (1.5 M) BEDS, 35
°
TROUGH
in.
mm
ORDERING
NUMBER
ITEM
CODE
WT.
LBS
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
24
600
8,100
DRXM-24-520 76856 403.0
DRXM-24-535 76872 403.0
30
750
8,100
DRXM-30-520 76857 435.0
DRXM-30-535 76873 435.0
36
900
9,500
DRXM-36-520 76858 514.0
DRXM-36-535 76874 514.0
42
1050
12,200
DRXM-42-520 76859 656.0
DRXM-42-535 76875 656.0
48
1200
13,600
DRXM-48-520 76860 687.0
DRXM-48-535 76876 687.0
54
1350
16,300
DRXM-54-520 76861 777.0
DRXM-54-535 76877 777.0
60
1500
17,600
DRXM-60-520 76862 861.0
DRXM-60-535 76878 861.0
72
1800
19,000
DRXM-72-520 76863 985.0
DRXM-72-535 76879 985.0
