Product Ordering
Information
DRX1500
Impact Beds
DRX1500
Lead time: 2 weeks
Lead time: 2 week
Replacement Parts
Lead time: 1 working day
Replacement Bars and Bolt Kits Required
per Belt Width - DRX1500
Impact Bed Size
Cema C or D,
5" IDLERS
CEMA C or D,
6" IDLERS
DRX1500: 24"- 36"
Shim idler up 1/2"
No Kits Required
DRX1500: 42"- 72"
No Kits Required
Use (1) SHIM-KITH;
Shim up 0.5"
Impact Bed Size
CEMA E,
6" IDLERS
CEMA E,
7" IDLERS
DRX1500: 36"-60"
Use (3) SHIM-KITH;
Shim up 1.5"
Use (4) SHIM-KITH;
Shim up 2"
DRX1500: 72"
Use (4) SHIM-KITH;
Shim up 2"
Use (5) SHIM-KITH;
Shim up 2.5"
in.
24 30 36 42 48 54 60 72
mm
600 750 900 1050 1200 1350 1500 1800
Slider Bars Required
2 2 2
2
2
2
2
2
Impact Bars Required
4 4 5
7
8
10 11 12
Impact Bar Supports Required
4 4 5
7
8
10 11 12
Impact Bar Bolt Kits Required
32 32 38 50 56 68 74 80
* Belt width + 9" = Structure width
5
1
2
6
7
1a
2a
3
4 4a
CEMA D construction
(hidden)
P R O D U C T H A N D B O O K
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1 Impact Bar, 4'
IB4
76926 17.0
2 Impact Bar, 5'
IB5
76927 21.2
3 Slider Bar, 4' (1.2M)
SB4
78789 20.0
3a Slider Bar, 5' (1.5M)
SB5
78790 24.1
4
Impact Bar Bolt Kit
incl. (1) ea 5/8" carriage bolt, square washer,
flat washer, lock washer, Nylock nut
IBBK 76928 0.5
5
Impact Bar Support -H 4'
incl. (1) bar support, (2) ea carriage bolt,
square washer, lock washer, Nylock nut
IBS-H4 76933 16.6
6
Impact Bar Support -H 5'
incl. (1) bar support, (2) ea carriage bolt,
square washer, lock washer, Nylock nut
IBS-H5 76934 21.0
7
Sliding Support Arm Bolt Kit
incl. (2) 2" bolts, (2) lock washers,
(2) Nylock nuts
ISABK-LMH 77529 2.0
8 Isolation Mount Kit
IMK 76936 3.8
9 DRX1500 Shim Kit
(incl. 8 shims)
SHIM-KITH 77550 27.2
BELT WIDTH TONNAGE
RATING
(ton/hr)
4' (1.2 M) BEDS, 20
°
TROUGH
4' (1.2 M) BEDS, 35
°
TROUGH
in.
mm
ORDERING
NUMBER
ITEM
CODE
WT.
LBS
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
24
600
12,800
DRXH-24-420 76880 503.0
DRXH-24-435 76896 503.0
30
750
12,800
DRXH-30-420 76881 545.0
DRXH-30-435 76897 545.0
36
900
14,900
DRXH-36-420 76882 628.0
DRXH-36-435 76898 628.0
42
1050
19,200
DRXH-42-420 76883 806.0
DRXH-42-435 76899 806.0
48
1200
21,300
DRXH-48-420 76884 847.0
DRXH-48-435 76900 847.0
54
1350
25,600
DRXH-54-420 76885 977.0
DRXH-54-435 76901 977.0
60
1500
27,700
DRXH-60-420 76886 1,066.0
DRXH-60-435 76902 1,066.0
72
1800
29,900
DRXH-72-420 76887 1,210.0
DRXH-72-435 76903 1,210.0
BELT WIDTH TONNAGE
RATING
(ton/hr)
5' (1.5 M) BEDS, 20
°
TROUGH
5' (1.5 M) BEDS, 35
°
TROUGH
in.
mm
ORDERING
NUMBER
ITEM
CODE
WT.
LBS
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
24
600
12,800
DRXH-24-520 76888 558.0
DRXH-24-535 76904 558.0
30
750
12,800
DRXH-30-520 76889 601.0
DRXH-30-535 76905 601.0
36
900
14,900
DRXH-36-520 76890 692.0
DRXH-36-535 76906 692.0
42
1050
19,200
DRXH-42-520 76891 896.0
DRXH-42-535 76907 896.0
48
1200
21,300
DRXH-48-520 76892 937.0
DRXH-48-535 76908 937.0
54
1350
25,600
DRXH-54-520 76893 1,084.0
DRXH-54-535 76909 1,084.0
60
1500
27,700
DRXH-60-520 76894 1,181.0
DRXH-60-535 76910 1,181.0
72
1800
29,900
DRXH-72-520 76895 1,334.0
DRXH-72-535 76911 1,334.0
