DRX200
Lead time: 2 weeks
Lead time: 2 weeks
Replacement Parts
Replacement Bars, Bar Supports and Bolt Kits
Required per Belt Width - DRX200
Impact Bed Size Cema C or D, 5" IDLERS CEMA C or D, 6" IDLERS
DRX200: 24"- 36"
Shim idler up 1/2"
No Kits Required
DRX200: 42"- 72"
No Kits Required
Use (1) SHIM-KITL;
Shim up 0.5"
Impact Bed Size CEMA E, 6" IDLERS CEMA E, 7" IDLERS
DRX200: 36"-60"
Use (3) SHIM-KITL;
Shim up 1.5"
Use (4) SHIM-KITL;
Shim up 2"
DRX200: 72"
Use (4) SHIM-KITL;
Shim up 2"
Use (5) SHIM-KITL;
Shim up 2.5"
Product Ordering
Information
DRX200
Impact Beds
in.
24 30 36 42 48 54 60 72
mm
600 750 900 1050 1200 1350 1500 1800
Slider Bars Required
2 2 2 2
2
2
2
2
Impact Bars Required
4 4 5 7
8 10 11 12
Impact Bar Supports Required
4 4 5 7
8 10 11 12
Impact Bar Bolt Kits Required
16 16 19 25 28 34 37 40
* Belt width + 9" = Structure width
U.S. Patent No. 7,815,040
5
1
2
6
7
1a
2a
3
4
4a
CEMA D construction
(hidden)
P R O D U C T H A N D B O O K
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1 Impact Bar, 4'
IB4
76926 17.0
1a Impact Bar, 5'
IB5
76927 21.2
2 Slider Bar, 4' (1.2M)
SB4
78789 20.0
2a Slider Bar, 5' (1.5M)
SB5
78790 24.1
3
Impact Bar Bolt Kit
incl. (1) ea 5/8" carriage bolt, square washer,
flat washer, lock washer, Nylock nut
IBBK
76928 0.5
4
Impact Bar Support -L 4'
incl. (1) ea bar support, carriage bolt,
square washer, lock washer, Nylock nut
IBS-L4
76929 16.8
4a
Impact Bar Support -L 5'
incl. (1) ea bar support, carriage bolt,
square washer, lock washer, Nylock nut
IBS-L5
76930 21.0
5
Sliding Support Arm Bolt Kit
incl. (2) 2" bolts, (2) lock washers,
(2) Nylock nuts
ISABK-LMH
77529 2.0
6 Isolation Mount Kit
IMK
76936 3.8
7 DRX200 Shim Kit
(incl. 4 shims)
SHIM-KITL
77548
13.6
Lead time: 1 working day
BELT WIDTH TONNAGE
RATING
(ton/hr)
4' (1.2 M) BEDS, 20
°
TROUGH
4' (1.2 M) BEDS, 35
°
TROUGH
in.
mm
ORDERING
NUMBER
ITEM
CODE
WT.
LBS
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
24
600
3500
DRXL-24-420 76816 260.0
DRXL-24-435 76832 260.0
30
750
3500
DRXL-30-420 76817 282.0
DRXL-30-435 76833 282.0
36
900
4100
DRXL-36-420 76818 323.0
DRXL-36-435 76834 323.0
42
1050
5200
DRXL-42-420 76819 412.0
DRXL-42-435 76835 412.0
48
1200
5800
DRXL-48-420 76820 433.0
DRXL-48-435 76836 433.0
54
1350
7000
DRXL-54-420 76821 498.0
DRXL-54-435 76837 498.0
60
1500
7600
DRXL-60-420 76822 543.0
DRXL-60-435 76838 543.0
72
1800
8100
DRXL-72-420 76823 615.0
DRXL-72-435 76839 615.0
BELT WIDTH TONNAGE
RATING
(ton/hr)
5' (1.5 M) BEDS, 20
°
TROUGH
5' (1.5 M) BEDS, 35
°
TROUGH
in.
mm
ORDERING
NUMBER
ITEM
CODE
WT.
LBS
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
24
600
3500
DRXL-24-520 76824 290.0
DRXL-24-535 76840 290.0
30
750
3500
DRXL-30-520 76825 311.0
DRXL-30-535 76841 311.0
36
900
4100
DRXL-36-520 76826 357.0
DRXL-36-535 76842 357.0
42
1050
5200
DRXL-42-520 76827 459.0
DRXL-42-535 76843 459.0
48
1200
5800
DRXL-48-520 76828 480.0
DRXL-48-535 76844 480.0
54
1350
7000
DRXL-54-520 76829 554.0
DRXL-54-535 76845 554.0
60
1500
7600
DRXL-60-520 76830 602.0
DRXL-60-535 76846 602.0
72
1800
8100
DRXL-72-520 76831 679.0
DRXL-72-535 76847 679.0
