58

DQC116

877.963.4966 •

dixonvalve.com

SCV-Series Pneumatic Couplings

Interchange Data:

Hansen FS-Series

Materials:

Machined components are manufactured using solid brass

bar stock.

Stainless steel springs and roll-pins maximize corrosion

resistance and extend service life.

Nitrile (Buna-N) seals are standard, providing a temperature

range of

-40°F

to

+250°F

(

-40°C

to

+121°C

).

Seal Components:

Does not prevent backflow

High flow design results in maximum flow with minimal

pressure drop.

Automatically and instantly protects the operator against

hose whip in the event of a damaged hose or coupling.

In the event of a hose rupture or coupling failure, the valve

will automatically reset after the problem is fixed.

SCV-Series is available in a large selection of sizes ranging

from ¼" to 3", NPTF (BSPP/BSPT threads on request).

Valve operation is fully compliant with OSHA Safety

Regulation 1926.302(b)(7), as shown on page 3.

Features:

Performance

Specifications

Maximum Operating

Pressure - Bar (PSI)

Minimum Burst

Pressure - Bar (PSI)

Air Flow

1

30.5m (100')

1/4"

17 (250)

138 (2,000)

17 SCFM

3/8"

17 (250)

138 (2,000)

41 SCFM

1/2"

17 (250)

138 (2,000)

77 SCFM

3/4"

17 (250)

138 (2,000)

178 SCFM

1"

17 (250)

138 (2,000)

340 SCFM

1-1/4"

17 (250)

138 (2,000)

620 SCFM

1-1/2"

17 (250)

138 (2,000)

940 SCFM

2"

17 (250)

138 (2,000)

1,760 SCFM

2-1/2"

17 (250)

138 (1,500)

2,800 SCFM

3"

17 (250)

138 (1,200)

4,200 SCFM

1

Air flow rating is based upon calculated values using unobstructed air flow for the applicable hose size.

Technical Specifications:

Use:

Safety check valves operate by using the pressure differential across the valve to operate the valve and spring assembly. The

pressure differential is directly related to the flow of air (SCFM) through the valve.

When the pressure differential is within the operating limits - below the cutoff flow - of the unit, the force on the valve exerted

by the spring is greater than that caused by the pressure differential (see "Open Position" graphic on next page). The valve

remains open and normal operation continues.

When the pressure differential is above the cutoff limit, the force on the valve exerted by the pressure differential is greater

than the force exerted by the spring, and the valve closes (see the "Closed Position" graphic graphic on next page).

After the repair is made, normal operation is automatically enabled when pressure across the valve equalizes through the

bleeder hole.

The valve spring size can be specified by determining the air flow during normal operation and by estimating the air flow if a

failure or rupture occurs.

Not recommended for applications requiring 100% of the available air supply. These applications include, but are

not limited to, sand blast equipment, pile driving rigs, and expansion joint blow down pipes. It is recommended to

install auxilliary safety devices, including Safety Cables, to ensure optimum safety for the operator in the event of a

coupling failure or hose rupture.
