DQC116

877.963.4966 •

dixonvalve.com

Interchange Data:

Dixon Quick Coupling Proprietary Astronautics

Materials:

Machined components are manufactured using solid steel or

brass bar stock.

Stainless steel balls, retaining rings, and springs maximize

corrosion resistance and extend service life.

Steel componentry is plated using ROHS Compliant

Trivalent Chrome.

Couplers are constructed of brass with steel valve as

standard.

Nitrile (Buna-N) seals are standard, providing a temperature

range of

-40°F

to

+250°F

(

-40°C

to

+121°C

).

Seal Components:

A-Series Pneumatic Couplings

Rated Pressure Chart:

Body

Size

A-Series Astronautics High Pressure Pneumatic (Connected)

Brass Coupler/Steel Plug

Brass Coupler/Plug

Maximum Working

Burst

Maximum Working

Burst

PSI

Bar

PSI

Bar

PSI

Bar

PSI

Bar

1/8"

1,000

70

18,500

1,275

500

35

15,500

1,070

1/4"

1,000

70

8,000

550

500

35

6,500

450

Technical Specifications:

Body

Size

Interchange Standards

Functional Parameters

U.S.

Military

U.S.

Government

International

Standards

ANSI/NFPA

Standards

Locking Ball

Quantity

Air

Inclusion

Fluid

Loss

Vacuum

Rating

Flow

ΔP = 15 PSI

1/8"

-

-

-

-

3

N/A

N/A

N/R 8.6 CFM

1/4"

-

-

-

-

3

N/A

N/A

N/R 26 CFM

Body

Size

A-Series Astronautics High Pressure Pneumatic Coupler (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/8"

1AF1-B 1/8" - 27 NPTF brass

$25.48

1.68 42.7 0.64 16.3 1/2" 0.08 10 100

1/4"

2AF1-B 1/8" - 27 NPTF brass

26.64

2.41 61.2 0.77 19.6 1/2" 0.17 10 100

1/4"

2AF2-B 1/4" - 18 NPTF brass

26.64

2.70 68.6 0.77 19.6 11/16" 0.16 10 100

List Price Seal Option Adders:

Body

Size

Seal Options

Valve Options

Sleeve Options

Treatments

FKM

EPDM Unvalved

Brass

303SS

Flanged Sleeve-Lock Oxy-Clean

Pre Add $ Pre Add $ Suf

Add $ Suf

Add $ Suf

Add $ Suf

Add $ Suf

Add $ Suf

Add $

1/8"

F-

N/A

P-

N/A

-E

-$.65

-BV

$.90

-SV

$.90

-FS

N/A

-LS

$5.00

-C1

$12.00

1/4"

F-

$2.00

P-

$2.50

-E

-3.80

-BV

N/A

-SV

N/A

-FS

N/A

-LS

8.90

-C1

16.00
