32

DQC116

877.963.4966 •

dixonvalve.com

CJ-Series Pneumatic Couplings

Body

Size

CJ-Series European Interchange Nipple (Female Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/4"

CJ2F2-LG 1/4" - 18 NPT

steel

$4.64

1.42 36.0 0.79 20.1 11/16" 0.07 10 100

1/4"

CJ2F2-B 1/4" - 18 NPT

brass

3.64

1.42 36.0 0.79 20.1 11/16" 0.06 10 100

1/4"

CJ2BF2-LG 1/4" - 19 BSPP steel

4.64

1.42 36.0 0.79 20.1 11/16" 0.07 10 100

1/4"

CJ2BF2-B 1/4" - 19 BSPP brass

3.64

1.42 36.0 0.79 20.1 11/16" 0.06 10 100

1/4"

CJ2F3-LG 3/8" - 18 NPT

steel

6.06

1.48 37.5 1.01 25.7 7/8" 0.10 10 100

1/4"

CJ2F3-B 3/8" - 18 NPT

brass

4.60

1.48 37.5 1.01 25.7 7/8" 0.09 10 100

1/4"

CJ2BF3-LG 3/8" - 19 BSPP steel

6.06

1.48 37.5 1.01 25.7 7/8" 0.10 10 100

1/4"

CJ2BF3-B 3/8" - 19 BSPP brass

4.60

1.48 37.5 1.01 25.7 7/8" 0.09 10 100

3/8"

CJ3F3

3/8" - 18 NPT

steel

6.09

1.50 38.0 1.01 25.7 7/8" 0.15 10 50

3/8"

CJ3F3-B 3/8" - 18 NPT

brass

4.29

1.50 38.0 1.01 25.7 7/8" 0.15 10 50

3/8"

CJ3BF3 3/8" - 19 BSPP steel

6.09

1.50 38.0 1.01 25.7 7/8" 0.15 10 50

3/8"

CJ3BF3-B 3/8" - 19 BSPP brass

4.29

1.50 38.0 1.01 25.7 7/8" 0.15 10 50

3/8"

CJ3F4

1/2" - 14 NPT

steel

7.35

1.71 43.5 1.16 29.5 1"

0.20 10 50

3/8"

CJ3F4-B 1/2" - 14 NPT

brass

4.78

1.71 43.5 1.16 29.5 1"

0.20 10 50

3/8"

CJ3BF4 1/2" - 14 BSPP steel

7.35

1.71 43.5 1.16 29.5 1"

0.20 10 50

3/8"

CJ3BF4-B 1/2" - 14 BSPP brass

4.78

1.71 43.5 1.16 29.5 1"

0.20 10 50

Body

Size

CJ-Series European Interchange Coupler (Male Threads)

Part Detail

List

Price

Length Maximum OD Hex

Inch

Weight

Lb

Package Qty

Part Number

Threads

Material

Inch mm Inch mm

Bag Box

1/4"

2CJM2-B 1/4" - 18 NPT

brass

$15.72

2.44 62.0 0.92 23.4 3/4" 0.25 10 100

1/4"

2CJBM2-B 1/4" - 19 BSPT brass

15.72

2.44 62.0 0.92 23.4 3/4" 0.25 10 100

1/4"

2CJM3-B 3/8" - 18 NPT

brass

16.75

2.44 62.0 0.92 23.4 3/4" 0.26 10 100

1/4"

2CJBM3-B 3/8" - 19 BSPT brass

16.75

2.44 62.0 0.92 23.4 3/4" 0.26 10 100

3/8"

3CJM3-B 3/8" - 18 NPT

brass

33.00

2.64 67.0 1.09 27.7 15/16" 0.42 10 50

3/8"

3CJBM3-B 3/8" - 19 BSPT brass

33.00

2.64 67.0 1.09 27.7 15/16" 0.42 10 50

3/8"

3CJM4-B 1/2" - 14 NPT

brass

35.34

2.76 70.0 1.09 27.7 15/16" 0.45 10 50

3/8"

3CJBM4-B 1/2" - 14 BSPT brass

35.34

2.76 70.0 1.09 27.7 15/16" 0.45 10 50
