• phone: 1-630-971-0150 80
3 3a
P V-Tip
5
Replacement
Parts List
P-Type®
Secondary Cleaner
1a
2
4
6
7
8
2a
2b
1
Tips Required per Cleaner Size
in. 18 24 30 36 42 48 54 60 72
mm 450 600 750 900 1050 1200 1350 1500 1800
C-Tips or V-Tips
Required 3 4 5 6 7 8 9 10 12
9
9
10
P R O D U C T H A N D B O O K
Replacement Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
18" (450mm) Pole PP-18 78414 22.5
24" (600mm) Pole PP-24 78416 26.0
30" (750mm) Pole PP-30 78418 32.3
36" (900mm) Pole PP-36 78420 33.0
42" (1050mm) Pole PP-42 78422 43.0
48" (1200mm) Pole PP-48 78424 47.5
54" (1350mm) Pole PP-54 78425 55.0
60" (1500mm) Pole PP-60 78451 58.0
72" (1800mm) Pole PP72 73017 64.0
1a
18" (450mm) LS Pole PLSP18 75595 32.3
24" (600mm) LS Pole PLSP24 75596 36.0
30" (750mm) LS Pole PLSP30 75597 38.7
36" (900mm) LS Pole PLSP36 75598 42.4
42" (1050mm) LS Pole PLSP42 75599 46.1
48" (1200mm) LS Pole PLSP48 75600 49.8
54" (1350mm) LS Pole PLSP54 75601 53.5
2 P2 C-Tip Cushion* PHA 73626 2.0
2a P Cushion SS Neoprene* (oil resistant) PSSC 77045 3.5
2b P Cushion Neoprene* (oil resistant) PNC 74984 3.5
3 P Polyshield PPS6 73024 0.5
3a P SS Shield PSSS 74773 0.5
4 C-Tip* Kit (1 ea.) ICT6 74535 0.7
5 P V-Tip* (for vulcanized belts only) PSA150 73156 1.0
6 Adjusting Bracket Kit* (1 ea.) PAB 75513 1.5
7
Pole Clamp Kit Left* (1 ea.)
(incl. 1 item 9)
for sizes 18"-54" (450-1350mm)
CCKL 79224 6.8
8
Pole Clamp Kit Right* (1 ea.)
(incl. 1 item 9)
for sizes 18"-54" (450-1350mm)
CCKR 79228 6.8
9
Cradle Clamp Top Strap (1 ea.)
For use on left or right Pole Clamp Kit CCKTS 79232 1.1
10
Mounting Bracket Kit
(1 Right and 1 Left) EZS2MBK 75666 13.0
-
Cradle Clamp Mounting Kit*
for sizes 18"-54" (450-1350mm)
(incl. 2 items 6 and 1 ea. item 7, 8 & 10)
CCMK 78919 33.0
*Hardware included
Lead time: 1 working day
