Blades Required per Cleaner Size*
in. 18 24 30 36 42 48
mm 450 600 750 900 1050 1200
Blades Required 6 8 10 12 14 16
*Blade segments are 3" each
4
6 7
7
6
3
8
5
2
1
9
11
10
12
14
13 15
12 14
Specifications
& Guidelines
Y-Type™
Secondary Cleaner with MSTTensioner
P R O D U C T H A N D B O O K
Replacement Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
18" (450mm) Y-Type Pole YTP-18 79587 20.2
24" (600mm) Y-Type Pole YTP-24 79588 22.7
30" (750mm) Y-Type Pole YTP-30 79589 25.2
36" (900mm) Y-Type Pole YTP-36 79590 27.7
42" (1050mm) Y-Type Pole YTP-42 79591 30.2
48" (1200mm) Y-Type Pole YTP-48 79592 32.7
2
18" (450mm) Y-Type Cushion Angle YTA-18 79593 5.7
24" (600mm) Y-Type Cushion Angle YTA-24 79594 7.3
30" (750mm) Y-Type Cushion Angle YTA-30 79595 8.9
36" (900mm) Y-Type Cushion Angle YTA-36 79596 10.4
42" (1050mm) Y-Type Cushion Angle YTA-42 79597 12.0
48" (1200mm) Y-Type Cushion Angle YTA-48 79598 13.6
3 Y-Type Angle Clamp* (incl. 2) YTAC 79623 2.2
4 MST Drop Bracket (incl. L & R brackets) MSTDB 79434 27.7
5 MST Adjusting Mechanism (incl. 1 ea.) MSTAM 79435 2.8
6 MST Mounting Bracket LH (incl. bushings) MST-MBL 79436 5.7
7 MST Mounting Bracket RH (incl. bushings) MST-MBR 79437 5.7
8 MST Clamp* (incl. 1 ea.) MSTC 79438 1.9
9 MST Bushing Kit (incl. 4 bushings) MSTBK 79440 .2
10 MST Guide Pole (incl. 1 ea.) MSTGT 79441 1.5
11 MST Pole Mount* (inc. 1 ea. non-handed) MSTPM 79452 6.3
- MST Tensioner w/White Spring (incl. 1 ea.
items 6 & 7; 2 ea. items 5, 8, 10 & 11 MST-W 79429 23.9
*Hardware included
Lead time: 1 working day
Replacement Blades/Blade Cartridges
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
12 Y-Type Purple Blade (single) YTC-P 79573 1.2
13
18" (450mm) Y-Type Purple Blade Cartridge YTC-P18 79617 13.1
24" (600mm) Y-Type Purple Blade Cartridge YTC-P24 79618 17.1
30" (750mm) Y-Type Purple Blade Cartridge YTC-P30 79619 21.1
36" (900mm) Y-Type Purple Blade Cartridge YTC-P36 79620 25.1
42" (1050mm) Y-Type Purple Blade Cartridge YTC-P42 79621 29.1
48" (1200mm) Y-Type Purple Blade Cartridge YTC-P48 79622 33.1
14 Y-Type White Blade (single)* YTC-W 79572 1.2
15
18" (450mm) Y-Type White Blade Cartridge* YTC-W18 79611 13.1
24" (600mm) Y-Type White Blade Cartridge* YTC-W24 79612 17.1
30" (750mm) Y-Type White Blade Cartridge* YTC-W30 79613 21.1
36" (900mm) Y-Type White Blade Cartridge* YTC-W36 79614 25.1
42" (1050mm) Y-Type White Blade Cartridge* YTC-W42 79615 29.1
48" (1200mm) Y-Type White Blade Cartridge* YTC-W48 79616 33.1
Lead time: 1 working day
White blades are chemical resistant, and all ingredients used in urethane formulation
comply with the relevant requirements of 21 CFR (FDA Code of Federal Regulations) for
use in repeated bulk dry food applications.
