U.S. Patent No. 6,823,983; 7,093,706
Specifications
& Guidelines
FMS
Flexco Medium-Duty Secondary Cleaner
Specifications
• Maximum Belt Speed ......................................................1000 FPM (5M/sec)
• Temperature Rating .........................................................-30°F to 180°F (-35°C to 82°C)
• Usable Blade Wear Length.............................................3/8" (9mm)
• Blade Materials ................................................................C-Tip: Impact Resistant Tungsten Carbide (works with mechanical fasteners)
.............................................................................................V-Tip: Long Life Tungsten Carbide (for vulcanized belts only)
• Available for Belt Widths ................................................18” to 72” (450 to 1800mm). Other sizes available upon request.
Overall Pole Length
Maximum Conveyor Span
Pole Length Specifications*
CLEANER SIZE BLADE WIDTH POLE LENGTH MAXIMUM
CONVEYOR SPAN
in.
mm in.
mm in.
mm in.
mm
18
450
18
450
72
1800
62
1550
24
600
24
600
78
1950
68
1700
30
750
30
750
84
2100
74
1850
36
900
36
900
90
2250
80
2000
42
1050
42
1050
96
2400
86
2150
48
1200
48
1200 102 2550
92
2300
54
1350
54
1350 108 2700
98
2450
60
1500
60
1500 114 2850
104
2600
72
1800
72
1800 126 3150
116
2900
*For special extra long pole length requirements a Pole Extender Kit (#76024) is
available that provides 30” (750mm) of extended pole length. (page 123).
Pole Diameter - 2-7/8” (73mm)
Clearance Guidelines for
Installation
HORIZONTAL
CLEARANCE
REQUIRED
VERTICAL
CLEARANCE
REQUIRED
in.
mm in.
mm
3-1/2
89
10
245
Vertical
Horizontal
Shading indicates preferred spring option. Measure
spring as shown.
MST Tensioner Spring Length Chart
Blade
Width
2 White
Springs
2 Silver
Springs
2 Black
Springs
in.
mm in.
mm in.
mm in.
mm
18 450 2 7/8 73 3 1/2 89 3 1/2 89
24 600 2 5/8 67 3 3/8 86 3 1/2 89
30 750 2 3/8 60 3 1/4 83 3 3/8 86
36 900 2 1/8 54 3 1/8 79 3 1/4 83
42 1050 N/A N/A 3 76 3 1/8 79
48 1200 N/A N/A 2 7/8 73 3 1/8 79
54 1350 N/A N/A 2 3/4 70 3 76
60 1500 N/A N/A 2 3/4 70 2 7/8 73
72 1800 N/A N/A N/A N/A 2 3/4 70
Bottom of Pole
Mount to Bottom
of Spring Support
Plate
