Specifications
& Guidelines
Y-Type ™
Secondary Cleaner with MSTTensioner
Specifications:
• Maximum Belt Speed...........................................600 FPM (3M/sec)
• Temperature Rating ..............................................-30°F to 180°F (-35°C to 82°C)
• Usable Blade Wear Length .................................2" (50mm)
• Blade Materials..................................................... Purple: Urethane (proprietary blend for abrasion
resistance and long wear)
................................................................................. White: Urethane (chemical resistant/food grade)
• Available for Belt Widths.....................................18" to 48" (450 to 1200mm)
Other sizes available upon request.
Overall Pole Length
Maximum Conveyor Span
Vertical
Horizontal
Y-Type™ Blade Specifications
Cushion Durometer
Temperature
Range
Purple (Standard) 86A -30° to 180°F
-35° to 82° C
White
(Chemical Resistant/
Food Grade) ‡
83A -30° to 180°F
-35° to 82° C
Pole Length Specifications
Cleaner
Size
Pole
Length
Maximum
Conveyor
Span
in. mm in. mm in. mm
18 450 48 1200 40 1025
24 600 54 1350 46 1175
30 750 60 1500 52 1325
36 900 66 1650 58 1475
42 1050 72 1800 64 1625
48 1200 78 1950 70 1775
Pole Length - Belt +30" (750mm)
Pole Diameter - 2-3/8” (60mm)
Clearance Guidelines for Installation
Cleaner
Type
BeltWidth/
Cleaner Size
Horizontal
Clearance
Required
Vertical
Clearance
Required
in. mm in. mm in. mm
Y-Type™ 18 - 48 450 - 1200 4-1/4 110 8-1/4 210
‡ All ingredients used in the urethane formulation of this blade comply
with the relevant requirements of 21 CFR (FDA Code of Federal
Regulations) for use in repeated bulk dry food applications
