U.S. Patent No. 6,823,983; 7,093,706
Replacement
Parts List
FMS
Flexco Medium-Duty Secondary Cleaner
Replacement Parts
2a
2b
4c
4b
4a
1
3
8
6
7
10
11
5
9
MST Spring Tensioner Selection Chart
CLEANER SIZE
79431
MSTHD-W
79432
MSTHD-S
79433
MSTHD-B
FMS 18" - 30"
(450 - 750mm)
X
FMS 36" - 54"
(900 - 1350mm)
X
FMS 60" - 72"
(1500 - 1800mm)
X
12
P R O D U C T H A N D B O O K
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
18" (450mm) Pole
MHSP-18 76178 46.2
24" (600mm) Pole
MHSP-24 75918 51.7
30" (750mm) Pole
MHSP-30 75919 57.2
36" (900mm) Pole
MHSP-36 75920 62.8
42" (1050mm) Pole
MHSP-42 75921 68.3
48" (1200mm) Pole
MHSP-48 75922 73.9
54" (1350mm) Pole
MHSP-54 75923 79.4
60" (1500mm) Pole
MHSP-60 75924 85.0
72" (1800mm) Pole
MHSP-72 75925 96.1
2a C-Tip*
ICT6
74535 0.7
2b V-Tip* (for vulcanized belts only)
RSA150 73628 1.3
3 FMS Cushion Kit*
FMSC 79699 4.2
4a Tension Spring - White (1 ea.) for belts 18" - 30" (450-750mm)
STS-W 75846 0.5
4b Tension Spring - Silver (1 ea.) for belts 36" - 54" (900-1350mm)
STS-S 75843 0.8
4c Tension Spring - Black (1 ea.) for belts 60" - 72" (1500-1800mm)
STS-B 75844 1.0
5 MST Adjusting Mechanism
MSTAM 79435 2.8
6 MST Mounting Bracket LH (incl. bushings)
MST-MBL 79436 5.7
7 MST Mounting Bracket RH (incl. bushings)
MST-MBR 79437 5.7
8 MST HD Clamp*
MSTCHD 79439 2.5
9 MST Bushing Kit (incl. 4 bushings)
MSTBK 79440
.2
10 MST Guide Pole
MSTGT 79441 1.5
11 MST HD Pole Mount*
MSTPMHD 79451 7.3
12 MST Drop Brackets (2)
MSTDB 79434 27.7
-
MST HD Tensioner w/White Spring*
(incl. 1 ea. items 6, 7; 2 ea. items 4a, 5, 8, 10 & 11)
MSTHD-W 79431 36.8
-
MST HD Tensioner w/Silver Spring*
(incl. 1 ea. items 6, 7; 2 ea. items 4b, 5, 8, 10 & 11)
MSTHD-S 79432 37.5
-
MST HD Tensioner w/Black Spring*
(incl. 1 ea. items 6, 7; 2 ea. items 4c, 5, 8, 10 & 11)
MSTHD-B 79433 38.1
*Hardware Included
Lead time: 1 working day
