Flexco Belt Cleaners Handbook GoodyearBelting.com 866-711-4673

77 / 206

• phone: 1-630-971-0150 77
P-Type® Secondary with C-Tips*
Replacement Tips Tips Required per Cleaner Size
Lead time: 1 working day
Product Notes:
• C-Tip: specially formulated tungsten carbide blades to work with mechanical fasteners.
• V-Tip: for use on vulcanized belts only.
• Compact design: fits in small transfer areas and tight chutes.
• Tips set at a non-aggressive 70º angle to give quick relief for passing mechanical splices.
P-Type® Secondary with V-Tips*
Product Ordering
Information
P-Type®
Secondary Cleaner
in. 18 24 30 36 42 48 54 60 72
mm 450 600 750 900 1050 1200 1350 1500 1800
C-Tips
or V-Tips
Required
3 4 5 6 7 8 9 10 12
P R O D U C T H A N D B O O K
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
ICT6 74535 0.7
PSA150 73156 1.0
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm
18 450 PC18 74566 72.4
24 600 PC24 74567 79.3
30 750 PC30 74568 85.2
36 900 PC36 74569 92.1
42 1050 PC42 74570 105.0
48 1200 PC48 74571 111.8
54 1350 PC54 74572 122.2
60 1500 PC60 74573 128.1
72 1800 PC72 74574 139.9
*NOTE: C-Tips can be used on mechanically spliced and
vulcanized belts.
Lead time: 1 working day
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm
18 450 PV-18 78453 72.4
24 600 PV-24 78415 79.3
30 750 PV-30 78417 85.2
36 900 PV-36 78419 92.1
42 1050 PV-42 78421 105.0
48 1200 PV-48 78423 111.8
54 1350 PV-54 78454 122.2
60 1500 PV-60 78455 128.1
72 1800 PV72 73438 139.9
*NOTE: V-Tips can be used ONLY on vulcanized belts.
Lead time: 1 working day
