U.S. Patent No. 6,823,983; 7,093,706
FMS Medium-Duty Secondary with C-Tips
Replacement Tips
Tips Required Per Cleaner Size
Product Notes:
• Recommended for medium-duty conveyor applications.
• Pole Length: Belt width plus 54" (1350mm). For longer requirements, see Mineline Installation
Accessories - Pole Extender Kit (page 123).
• Cushion is designed to maintain continuous blade-to-belt contact and quick relief from passing
mechanical splices.
• C-Tips are for mechanically fastened or vulcanized belts. V-Tips are for vulcanized belts only.
• Visual Blade Tension Check: Measure the tension spring and refer to Spring Length Chart for the
correct length for best cleaning performance.
• Tensioner: MST Spring Tensioner for self-adjusting tensioning with easy retensioning adjustments.
• To make cleaner installation easier and quicker, see Optional Drop Brackets on page 86.
FMS Medium-Duty Secondary with V-Tips
Product Ordering
Information
FMS
Flexco Medium-Duty Secondary Cleaner
(MSTTensioners)
in.
18
24
30
36
42
48
54
60
72
mm
450 600 750 900 1050 1200 1350 1500 1800
C-Tips or V-Tips
Required
3
4
5
6
7
8
9
10
12
P R O D U C T H A N D B O O K
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
18
450
FMS-18
79637 98.7
24
600
FMS-24
79638 111.2
30
750
FMS-30
79639 123.6
36
900
FMS-36
79640 136.1
42
1050
FMS-42
79641 148.6
48
1200
FMS-48
79642 161.1
54
1350
FMS-54
79643 173.5
60
1500
FMS-60
79644 186.0
72
1800
FMS-72
79645 211.0
Lead time: 1 working day
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
18
450
FMS-18V 79646
98.7
24
600
FMS-24V 79647 111.2
30
750
FMS-30V 79648 123.6
36
900
FMS-36V 79649 136.1
42
1050
FMS-42V 79650 148.6
48
1200
FMS-48V 79651 161.1
54
1350
FMS-54V 79652 173.5
60
1500
FMS-60V 79653 186.0
72
1800
FMS-72V 79654 211.0
*NOTE: V-Tips can be used ONLY on vulcanized belts.
Lead time: 1 working day
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
ICT6
74535 0.7
RSA150
73628 1.3
Lead time: 1 working day
