Specifications
& Guidelines
H-Type with XF2-Tips
Segmented Blade Precleaner
Specifications:
• Maximum Belt Speed.....................................................1000 FPM (5M/sec)
• Temperature Rating ........................................................-30°F to 180°F (-35°C to 82°C)
• Usable Blade Wear Length ...........................................3" (75mm)
• Blade Material.................................................................Urethane (proprietary blend for
...........................................................................................abrasion resistance and long wear)
• Available for Belt Widths...............................................18" to 72" (450mm to 1800mm).
...........................................................................................Other sizes available upon request.
Overall Pole Length
Maximum Conveyor Span
Pole Length Specifications*
Clearance Guidelines for Installation
Spring Length Chart
with QMT Spring Tensioner
*For special extra long pole length requirements a Pole Extender Kit
(#76024) is available that provides 30" (750mm) of extended pole length.
(page 123).
Pole Diameter - 2-7/8" (73mm)
Top of washer
to top of
torque arm
U.S. Patent No. 6.926,133
Purple Spring
Silver Spring
White Spring
Horizontal
Vertical
SUSPENSION
ARM SIZE
HORIZONTAL
CLEARANCE
REQUIRED
VERTICAL
CLEARANCE
REQUIRED
in.
mm in.
mm
SS
7
175
13
325
S
7
175
15
375
M
7
175
16 1/2
413
L
7
175
18 1/2
463
LL
7
175
22
550
BELT
WIDTH TIPS
SPRING LENGTH
SS
S
M L
18"
2
4 1/2"
4"
5 3/4"
N/A
24"
3
5 5/8"
5 1/2"
5 3/8"
N/A
30"
3
5 5/8"
5 1/2"
5 3/8"
N/A
36"
4
5 3/8"
5 1/8"
5"
4 1/4"
42"
5
5"
4 3/4"
6"
6"
48"
5
5"
4 3/4"
6"
6"
54"
6
4 3/4"
6"
5 7/8"
5 7/8"
60"
7
N/A 5 7/8"
5 3/4"
5 3/4"
72"
8
N/A 5 3/4"
5 5/8"
5 5/8"
CLEANER SIZE
POLE LENGTH
MAXIMUM
CONVEYOR SPAN
in.
mm in.
mm in.
mm
18
450
66
1650
56
1400
24
600
72
1800
62
1550
30
750
78
1950
68
1700
36
900
84
2100
74
1850
42
1050
90
2250
80
2000
48
1200
96
2400
86
2150
54
1350
102
2550
92
2300
60
1500
108
2700
98
2450
72
1800
120
3000
110
2750
