Specifications:
• Maximum Belt Speed...........................................1500 FPM (7.5M/sec)
• Temperature Rating ..............................................-30°F to 180°F (-35°C to 82°C)
• Usable Blade Wear Length .................................3/8" (9mm)
• Blade Material.......................................................Long Life Tungsten Carbide
(for vulcanized belts only)
• Available for Belt Widths.....................................18" to 72" (450mm to 1800mm)
Other sizes available upon request.
Overall Pole Length
Maximum Conveyor Span
Top of
washer
to top of
torque arm
Clearance Guidelines for Installation
Suspension
Arm Size
Horizontal
Clearance
Required
Vertical
Clearance
Required
in.
mm in.
mm
SS
8-1/4
210
12-5/8
320
S
8-1/4
210
15-3/8
390
M
8-1/4
210
16-5/8
416
L
8-1/4
210
17-1/2
445
LL
8-1/4
210
20-1/8
511
Pole Length Specifications*
Cleaner Size
Pole Length
Maximum
Conveyor Span
in.
mm in.
mm in.
mm
18
450
66
1650
56
1400
24
600
72
1800
62
1550
30
750
78
1950
68
1700
36
900
84
2100
74
1850
42
1050
90
2250
80
2000
48
1200
96
2400
86
2150
54
1350
102
2550
92
2300
60
1500
108
2700
98
2450
72
1800
120
3000
110
2750
*For special extra long pole length requirements a Pole Extender Kit
(#76024) is available that provides 30” (750mm) of extended pole length.
Pole Diameter - 2-7/8” (73mm) (page 123)
Horizontal
Vertical
HV2 Spring Length Chart
(for optimal blade tensioning)
Belt
Width Tips
Spring Length
SS
S
M L
LL
in mm
in mm in mm in mm in mm in mm
18"
450
2 5 1/4" 133 4 7/8" 124 4 3/4" 121 4 1/2" 114 N/A N/A
24"
600
3 4 1/2" 114 4 1/8" 105 5 3/4" 146 5 3/4" 146 N/A N/A
30"
750
4 4 1/2" 114 4 1/8" 105 5 3/4" 146 5 3/4" 146 N/A N/A
36"
900
5 5 3/4" 146 5 5/8" 143 5 1/2" 140 5 3/8" 137 N/A N/A
42"
1050 6 5 5/8" 143 5 3/8" 137 5 1/4" 133 5 1/8" 130 4 3/4" 121
48"
1200 7 5 5/8" 143 5 3/8" 137 5 1/4" 133 5 1/8" 130 4 3/4" 121
54"
1350 8 N/A N/A 5 1/8" 130 5 127 4 7/8" 124 6"
152
60"
1500 9 N/A N/A 4 7/8" 124 6 1/8" 156 6"
152 5 7/8" 150
72"
1800 11 N/A N/A 6"
152 6"
152 5 7/8" 150 5 3/4" 146
Purple Spring
Silver Spring
White Spring
Specifications
& Guidelines
HV2
Segmented Blade Precleaner
