Specifications

& Guidelines

H-Type with V-Tips

Segmented Blade Precleaner

Specifications:

• Maximum Belt Speed.....................................................1000 FPM (5M/sec)

• Temperature Rating ........................................................-30°F to 180°F (-35°C to 82°C)

• Usable Blade Wear Length ...........................................3/8" (9mm)

• Blade Material.................................................................Long Life Tungsten Carbide

...........................................................................................(for vulcanized belts only)

• Available for Belt Widths...............................................18" to 72" (450mm to 1800mm)

...........................................................................................Other sizes available upon request.

Horizontal

Vertical

Overall Pole Length

Maximum Conveyor Span

Spring Length Chart

with QMT Spring Tensioner

Pole Length Specifications*

Clearance Guidelines

for Installation

*For special extra long pole length requirements a Pole Extender Kit

(#76024) is available that provides 30" (750mm) of extended pole length.

(page 123).

Pole Diameter - 2-7/8" (73mm)

Top of washer

to top of torque

arm

Purple Spring

Silver Spring

White Spring

BELT

WIDTH TIPS

SPRING LENGTH

SS

S

M L

LL

18"

2

5 1/4"

4 7/8"

4 3/4"

4 1/2"

N/A

24"

3

4 1/2"

4 1/8"

5 3/4"

5 3/4"

N/A

30"

3

4 1/2"

4 1/8"

5 3/4"

5 3/4"

N/A

36"

4

5 3/4"

5 5/8"

5 1/2"

5 3/8"

N/A

42"

5

5 5/8"

5 3/8"

5 1/4"

5 1/8"

4 3/4"

48"

5

5 5/8"

5 3/8"

5 1/4"

5 1/8"

4 3/4"

54"

6

N/A 5 1/8"

5

4 7/8"

6"

60"

7

N/A 4 7/8"

6 1/8"

6"

5 7/8"

72"

8

N/A

6"

6"

5 7/8"

5 3/4"

SUSPENSION

ARM SIZE

HORIZONTAL

CLEARANCE

REQUIRED

VERTICAL

CLEARANCE

REQUIRED

in.

mm in.

mm

SS

7

175

13

325

S

7

175

15

375

M

7

175

16 1/2

413

L

7

175

18 1/2

463

LL

7

175

22

550

CLEANER SIZE

POLE LENGTH

MAXIMUM

CONVEYOR SPAN

in.

mm in.

mm in.

mm

18

450

66

1650

56

1400

24

600

72

1800

62

1550

30

750

78

1950

68

1700

36

900

84

2100

74

1850

42

1050

90

2250

80

2000

48

1200

96

2400

86

2150

54

1350

102

2550

92

2300

60

1500

108

2700

98

2450

72

1800

120

3000

110

2750
