66
Product Ordering
Information
H-Type with Protected V-Tips
Segmented Blade Precleaner
Suspension Arm Size
Replacement
Suspension Arms
Replacement
Protected V-Tips
Tips Required per Cleaner Size
For abusive applications where materials being cleaned off
the belt wear the back sides of the cleaner’s V-Tips.
Lead time: 1 working day
Lead time: 1 working day
H-Type
®
with Protected V-Tips*
H-Type Precleaner with HVP-Tips
• 2 7/8" (73mm) diameter pole.
HEAD PULLEY DIAMETER
+ BELT & LAGGING
SUSPENSION
ARM SIZE
in.
mm
10 - 19
250-475
SS
20 - 31
500-775
S
32 - 39
800-975
M
40 - 47
1000-1175
L
48 - 67
1200-1675
LL
in.
18
24
30
36
42
48
54
60
72
mm
450 600 750 900 1050 1200 1350 1500 1800
Protected
V-Tips Required
2
3
3
4
5
5
6
7
8
P R O D U C T H A N D B O O K
BELT WIDTH SUSPENSION
ARM SIZE
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
18
450
S
HVP-18S 76124 99.1
18
450
M HVP-18M 76267 100.1
18
450
L
HVP-18L 76268 100.9
24
600
S
HVP-24S 76125 112.8
24
600
M HVP-24M 76269 114.3
24
600
L
HVP-24L 76270 115.5
30
750
S
HVP-30S 76126 116.6
30
750
M HVP-30M 76271 118.1
30
750
L
HVP-30L 76272 119.3
36
900
S
HVP-36S 76127 130.4
36
900
M HVP-36M 76273 133.8
36
900
L
HVP-36L 76274 135.4
42
1050
S
HVP-42S 76128 145.6
42
1050
M HVP-42M 76275 148.1
42
1050
L
HVP-42L 76276 150.1
48
1200
S
HVP-48S 76129 149.4
48
1200
M HVP-48M 76277 151.9
48
1200
L
HVP-48L 76278 153.9
48
1200
LL
HVP-48LL 76279 156.4
54
1350
S
HVP-54S 76130 163.2
54
1350
M HVP-54M 76280 166.2
54
1350
L
HVP-54L 76281 168.6
54
1350
LL
HVP-54LL 76282 171.6
60
1500
S
HVP-60S 76131 201.1
60
1500
M HVP-60M 76283 204.6
60
1500
L
HVP-60L 76284 207.4
60
1500
LL
HVP-60LL 76285 213.0
72
1800
S
HVP-72S 76132 222.7
72
1800
M HVP-72M 76286 226.7
72
1800
L
HVP-72L 76287 232.0
72
1800
LL
HVP-72LL 76288 236.0
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
HVPT
73631 2.7
SIZE
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
SS
HSA8SS 73047
2.0
S
HSA8S
73048
2.4
M HSA8M 73049
2.9
L
HSA8L
73063
3.3
LL
HSA8LL
73064
3.8
*NOTE: Protected V-Tips can be used ONLY on vulcanized belts.
Suspension arm size is determined by head pulley
diameter - see chart.
Cleaners come standard with Stainless Steel Tip Shields.
Additional sizes available upon request.
Lead time: 1 working day
