Telescoping Pole Length Specifications
Specifications:
• Maximum Belt Speed..................................... 1200 FPM (6M/sec)
• Temperature Rating ........................................ -30°F to 180°F (-35°C to 82°C)
• Minimum Pulley Diameter ............................. 20" (500mm)
• Blade Height .................................................... 14" (350mm)
• Usable Blade Wear Length ........................... 8" (200mm)
• Blades............................................................... Urethane (proprietary blend for
........................................................................... abrasion resistance and long wear).
• Available for Belt Widths............................... 24" to 96" (600 to 2400mm).
........................................................................... Other sizes available upon request.
Clearance Guidelines for
Installation
PSI setting is based on the number of
blades on the cleaner, not the belt width.
Spring Length Chart
with PST Spring Tensioner
Air/Water or Nitrogen
Pressure Chart
Maximum Overall Pole Length
Maximum Conveyor Span
Center Pole Length
Top of
washer to
top of
torque arm
Spring tension is based on the number of blades
on the cleaner, not the belt width.
Shading indicates preferred spring option
Pole Location Specs
A = Pulley Diameter + Lagging and Belt
C = Critical Spec to move location if necessary
A
X
C
Y
BLADE
WIDTH
NO. OF
BLADES
WHITE
SPRINGS
SILVER
SPRINGS
RED
SPRINGS
18"
3
5 3/4"
6 3/8"
6 1/2"
24"
4
5 3/8"
6 1/4"
6 3/8"
30"
5
5 1/8"
6 1/8"
6 3/8"
36"
6
4 3/4"
6 1/8"
6 1/4"
42"
7
4 1/2"
6"
6 1/4"
48"
8
N/A 5 7/8"
6 1/8"
54"
9
N/A 5 3/4"
6 1/8"
60"
10
N/A 5 3/4"
6"
66"
11
N/A 5 5/8"
6"
72"
12
N/A 5 1/2"
5 7/8"
78"
13
N/A 5 1/8”
5 3/4"
84"
14
N/A N/A 5 3/4"
90"
15
N/A N/A 5 5/8"
Pole Location Chart
Move Dim.
C on arc
Pole Diameter - 2-7/8" (73mm)
HORIZONTAL
CLEARANCE
REQUIRED
VERTICAL
CLEARANCE
REQUIRED
in.
mm in.
mm
7
175
19
475
CLEANER SIZE
MAX OVERALL
POLE LENGTH
CENTER POLE
LENGTH
MAXIMUM
CONVEYOR SPAN
in.
mm in.
mm in.
mm in.
mm
24
600
82
2050
28
700
66
1650
30
750
88
2200
34
850
72
1800
36
900
94
2350
40
1000
78
1950
42
1050
100
2500
46
1150
84
2100
48
1200
106
2650
52
1300
90
2250
54
1350
112
2800
58
1450
96
2400
60
1500
118
2950
64
1600
102
2550
72
1800
130
3250
76
1900
114
2850
84
2100
142
3550
88
2200
126
3150
96
2400
154
3850
100
2500
138
3450
A
X
Y
C
20"
10"
14 3/8"
17 1/2"
21"
10 1/2"
14 3/8"
17 3/4"
22"
11"
14 3/8"
18 1/8"
23"
11 1/2"
14 3/8"
18 3/8"
24"
12"
14 3/8"
18 3/4"
25"
12 1/2"
14 3/8"
19"
26"
13"
14 3/8"
19 3/8"
27"
13 1/2"
14 3/8"
19 3/4"
28"
14"
14 3/8"
20 1/8"
29"
14 1/2"
14 3/8"
20 3/8"
30"
15"
14 3/8"
20 3/4"
31"
15 1/2"
14 3/8"
21 1/8"
32"
16"
14 3/8"
21 1/2"
33"
16 1/2"
14 3/8"
21 7/8"
34"
17"
14 3/8"
22 1/4"
35"
17 1/2"
14 3/8"
22 5/8"
36"
18"
14 3/8"
23"
37"
18 1/2"
14 3/8"
23 3/8"
38"
19"
14 3/8"
23 7/8"
39"
19 1/2"
14 3/8"
24 1/4"
40"
20"
14 3/8"
24 5/8"
41"
20 1/2"
14 3/8"
25"
42"
21"
14 3/8"
25 1/2"
43"
21 1/2"
14 3/8"
25 7/8"
44"
22"
14 3/8"
26 1/4"
45"
22 1/2"
14 3/8"
26 3/4"
46"
23"
14 3/8"
27 1/8"
47"
23 1/2"
14 3/8"
27 1/2"
48"
24"
14 3/8"
28"
BLADE
WIDTH BLADES PSI
18"
3
8#
24"
4
10#
30"
5
13#
36"
6
15#
42"
7
18#
48"
8
20#
54"
9
23#
60"
10
25#
66"
11
28#
72"
12
31#
78"
13
33#
84"
14
36#
90"
15
38#
Specifications
& Guidelines
MHCP
Heavy-Duty Cartridge Precleaner
Vertical
Horizontal
