52

Pole Location Specs

A = Pulley Diameter + Lagging and Belt

C = Critical Spec to move location if necessary

A

X

C

Y

Move Dim. C

on arc

X &Y Chart for Pole Location

Pulley Diameter

(including belt

and lagging)

X Y C

20"

10"

14-3/8" 17-1/2"

21"

10-1/2" 14-3/8" 17-3/4"

22"

11"

14-3/8" 18-1/8"

23"

11-1/2" 14-3/8" 18-3/8"

24"

12"

14-3/8" 18-3/4"

25"

12-1/2" 14-3/8"

19"

26"

13"

14-3/8" 19-3/8"

27"

13-1/2" 14-3/8" 19-3/4"

28"

14"

14-3/8" 20-1/8"

29"

14-1/2" 14-3/8" 20-3/8"

30"

15"

14-3/8" 20-3/4"

31"

15-1/2" 14-3/8" 21-1/8"

32"

16"

14-3/8" 21-1/2"

33"

16-1/2" 14-3/8" 21-7/8"

34"

17"

14-3/8" 22-1/4"

35"

17-1/2" 14-3/8" 22-5/8"

36"

18"

14-3/8"

23"

37"

18-1/2" 14-3/8" 23-3/8"

38"

19"

14-3/8" 23-7/8"

39"

19-1/2" 14-3/8" 24-1/4"

40"

20"

14-3/8" 24-5/8"

41"

20-1/2" 14-3/8"

25"

42"

21"

14-3/8" 25-1/2"

43"

21-1/2" 14-3/8" 25-7/8"

44"

22"

14-3/8" 26-1/4"

X &Y Chart for Pole Location

Pulley Diameter

(including belt

and lagging)

X Y C

45"

22-1/2" 14-3/8" 26-3/4"

46"

23"

14-3/8" 27-1/8"

47"

23-1/2" 14-3/8" 27-1/2"

48"

24"

14-3/8"

28"

49"

24-5/8" 14-3/8" 28-1/2"

50"

25-1/8" 14-3/8"

29"

51"

25-3/4" 14-3/8" 29-1/2"

52"

26-3/8" 14-3/8"

30"

53"

26-7/8" 14-3/8" 30-1/2"

54"

27-1/2" 14-3/8"

31"

55"

28-1/8" 14-3/8" 31-1/2"

56"

28-5/8" 14-3/8"

32"

57"

29-1/8" 14-3/8" 32-1/2"

58"

29-3/4" 14-3/8"

33"

59"

30-1/4" 14-3/8" 33-1/2"

60"

30-7/8" 14-3/8"

34"

61"

31-3/8" 14-3/8" 34-1/2"

62"

31-7/8" 14-3/8"

35"

63"

32-1/2" 14-3/8" 35-1/2"

64"

33"

14-3/8"

36"

65"

33-1/2" 14-3/8" 36-1/2"

66"

34-1/8" 14-3/8"

37"

67"

34-5/8" 14-3/8" 37-1/2"

68"

35-1/8" 14-3/8"

38"

69"

35-3/4" 14-3/8" 38-1/2"

X &Y Chart for Pole Location

Pulley Diameter

(including belt

and lagging)

X Y C

70"

36-1/4" 14-3/8"

39"

71"

36-3/4" 14-3/8" 39-1/2"

72"

37-3/8" 14-3/8"

40"

73"

37-7/8" 14-3/8" 40-1/2"

74"

38-3/8" 14-3/8"

41"

75"

38-7/8" 14-3/8" 41-1/2"

76"

39-1/2" 14-3/8"

42"

77"

40"

14-3/8" 42-1/2"

78"

40-1/2" 14-3/8"

43"

79"

41"

14-3/8" 43-1/2"

80"

41-5/8" 14-3/8"

44"

81"

42-1/8" 14-3/8" 44-1/2"

82"

42-5/8" 14-3/8"

45"

83"

43-1/8" 14-3/8" 45-1/2"

84"

43-3/4" 14-3/8"

46"

Specifications

& Guidelines

MHP

MineTough Heavy-Duty Precleaner
