53 / 206
www.flexco.com
• phone: 1-630-971-0150
53
9
10
11
12
13
6
8
2
6a
6b
3
4
1
5
7
Replacement
Parts List
MHP
MineTough Heavy-Duty Precleaner
Spring Tensioner Selection Chart
CLEANER BLADE WIDTH
77723
PST2-W
77724
PST2-S
77725
PST2-R
MegaShear 18" - 42" (450 - 1050mm)
X
MegaShear 48" - 78" (1200 - 1950mm)
X
MegaShear 84" - 90" (2100 - 2250mm)
X
P R O D U C T H A N D B O O K
PAT Air & Nitrogen Tensioner Replacement Parts
*Hardware Included
Lead time: 1 working day
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
9 Air/Water Bag
(1 ea.)
AWTB 75905 3.8
10 Mounting Base
(1 ea.)
AWTMB 75906 22.9
11 Torque Arm
*
(1 ea.)
AWTA 75907 11.6
12 Hose Kit
(50' of hose and 6 hose clamps)
AWTHK 75909 6.7
13 PAT Control Box
PACB 78683 11.0
-
PAT Kit- AWT Tensioner w/Control Box
(includes 2 ea. Items 9, 10, 11 & 1 ea. Items 12, 13)
PAK 78705 86.2
-
AWT Air/Water Tensioner w/o Control Box
(includes 2 each items 9, 10, 11 & 1 each item 12)
AWTNCB 76069 75.2
Replacement Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
24" (600mm) Center Pole
MMPCP24 76458 34.4
30" (750mm) Center Pole
MMPCP30 76459 43.0
36" (900mm) Center Pole
MMPCP36 76460 51.6
42" (1050mm) Center Pole
MMPCP42 76461 60.1
48" (1200mm) Center Pole
MMPCP48 76462 68.7
54" (1350mm) Center Pole
MMPCP54 76463 77.3
60" (1500mm) Center Pole
MMPCP60 76464 85.9
72" (1800mm) Center Pole
MMPCP72 76465 103.1
84" (2100mm) Center Pole
MMPCP84 76808 120.3
96" (2400mm) Center Pole
MMPCP96 77722 137.5
2 Extender Pole Kit
(2 ea.)
MHP-EP 76392 54.0
3 Mounting Plate Kit*
(2 ea.)
MHPMPK 77727 44.4
4 Blade Pin Kit*
(1 ea.)
MHPBPK 77728 0.8
5 Torque Pivot Kit*
(1 ea.)
PTPK 75897 7.0
6 Tension Spring - White
(1 ea.)
for blades 18" - 42" (450 - 1050mm)
PSTS-W 75898 1.7
6a Tension Spring - Silver
(1 ea.)
for blades 48" - 78" (1200 - 1950mm)
PSTS-S 75899
3.0
6b Tension Spring - Red
(1 ea.)
for blades 84" - 90" (2100 - 2250mm)
PSTS-R 77726
4.3
7 Torque Arm Kit*
(1 ea.)
PSTA 75896 11.4
8 Bushing Kit
(2 ea.)
QMTBK-W 76098 0.2
-
PST Spring Tensioner* - White
(incl. 2 ea. Items 3, 5, 6, 7, & 8)
for blades 18" - 42" (450 - 1050mm)
PST2-W 77723 86.1
-
PST Spring Tensioner* - Silver
(incl. 2 ea. Items 3, 5, 6a, 7, & 8)
for blades 48" - 78" (1200 - 1950mm)
PST2-S 77724 87.4
-
PST Spring Tensioner* - Red
(incl. 2 ea. Items 3, 5, 6b, 7 & 8)
for blades 84" - 90" (2100 - 2250mm)
PST2-R 77725 88.8
*Hardware Included
Lead Time: 1 working day
