Replacement
Parts List
EZSB-I
Flexco Slider Beds
CoreTech™ Impact Rolls
in.
24
30
36
42
48
54
60
72
mm
600
750
900
1050
1200
1350
1500
1800
ROLLS REQUIRED
4
4
4
4
4
4
4
4
BARS REQUIRED
SLIDER
2
2
2
2
2
2
2
2
IMPACT
2
2
2
4
4
6
6
6
BAR BOLT KITS REQUIRED
10
10
10
16
16
22
22
22
BAR SUPPORTS REQUIRED
2
2
2
4
4
6
6
6
IMPACT BED
SIZE
CEMA C OR D, 5” (125mm)
Idlers
CEMA C OR D, 6” (150mm)
IDLERS
24"-36"
(600-900mm)
Shim idler up .5" (12.5mm)
No Kits Required
42"-72"
(1050-1800mm)
No Kits Required Use (1) SHIM-KITL; Shim
up .5" (12.5mm)
Shim Requirements
IMPACT BED
SIZE
CEMA E, 6” (150mm)
IDLERS
CEMA E, 7” (175mm)
IDLERS
36"-60"
(900-1500mm)
Use (3) SHIM-KITL; Shim
up 1.5" (37.5mm)
Use (4) SHIM-KITL; Shim
up 2" (50mm)
72"
(1800mm)
Use (4) SHIM-KITL; Shim
up 2" (50mm)
Use (5) SHIM-KITL; Shim
up 2.5" (62.5mm)
Replacement Quantities for EZSB-I
1
2
1a
2a
3
(hidden)
4
6
5
5a
7
8
9
U.S. Patent pending
P R O D U C T H A N D B O O K
Replacement Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
Slider Bar, 4' (1.2M)
SB4
78789
20.0
1a
Slider Bar, 5' (1.5M)
SB5
78790
24.1
2
Impact Bar, 4’ (1.2M)
IB4
76926
17.0
2a
Impact Bar, 5’ (1.5M)
IB5
76927
21.0
3
Bar Bolt Kit
(incl. 1 ea. 5/8”(15mm)
carriage bolt, square washer, flat washer,
lock washer, Nylock nut)
IBBK
76928
0.5
4
Impact Slider Mount Kit *
EZIRMK
79318
5.1
5
Impact Bar Support - L 4’ (1.2M) *
EZBS-L4
78953
16.1
5a
Impact Bar Support - L 5’ (1.5M) *
EZBS-L5
78954
20.4
6
Impact CoreTech™ Roll 24" (600mm)
NI6D3T-24-9-A45
26184
10.1
Impact CoreTech Roll 30" (750mm)
NI6D3T-30-11-A45 26185
12.0
Impact CoreTech Roll 36" (900mm)
NI6D3T-36-13-A45 26186
13.9
Impact CoreTech Roll 42" (1050mm)
NI6D3T-42-15-A45 26187
16.0
Impact CoreTech Roll 48" (1200mm)
NI6D3T-48-17-A45 26188
17.9
Impact CoreTech Roll 54" (1350mm)
NI6D3T-54-19-A45 26189
19.8
Impact CoreTech Roll 60" (1500mm)
NI6D3T-60-21-A45 26190
21.7
Impact CoreTech Roll 72" (1800mm)
NI6D3T-72-25-A45 26191
25.6
7
Wing Plate Kit 24" (600mm) *
EZWPK-24
78970
16.9
Wing Plate Kit 30" (750mm) *
EZWPK-30
78971
17.4
Wing Plate Kit 36" (900mm) *
EZWPK-36
78972
21.2
Wing Plate Kit 42" (1050mm) *
EZWPK-42
78973
26.2
Wing Plate Kit 48" (1200mm) *
EZWPK-48
78974
30.1
Wing Plate Kit 54" (1350mm) *
EZWPK-54
78975
35.6
Wing Plate Kit 60" (1500mm) *
EZWPK-60
78976
39.0
Wing Plate Kit 72" (1800mm) *
EZWPK-72
78977
46.7
8
Cross Stringer Kit 24" (600mm) *
EZCSK-24
78978
49.2
Cross Stringer Kit 30" (750mm) *
EZCSK-30
78979
56.5
Cross Stringer Kit 36" (900mm) *
EZCSK-36
78980
63.8
Cross Stringer Kit 42" (1050mm) *
EZCSK-42
78981
70.8
Cross Stringer Kit 48" (1200mm) *
EZCSK-48
78982
78.5
Cross Stringer Kit 54" (1350mm) *
EZCSK-54
78983
85.8
Cross Stringer Kit 60" (1500mm) *
EZCSK-60
78984
93.1
Cross Stringer Kit 72" (1800mm) *
EZCSK-72
78985
99.1
9
Shim Kit Light Duty
(incl. 4 shims)
SHIM-KITL
77548
13.6
*Hardware Included
Lead time: 1 working day
