U.S. Patent No. 6,823,983; 7,093,706
MHS HD Secondary with C-Tips
Replacement Tips
Replacement Cushion Shield
Tips Required Per Cleaner Size
Product Notes:
• Heavy-duty design to deliver maximum cleaning efficiency on the most demanding, abusive beltlines.
• Pole Length: Belt width plus 54" (1350mm). For longer requirements, see Mineline Installation Accessories - Pole
Extender Kit (page 123).
• Patented PowerFlex
™
cushion design to maintain continuous blade-to-belt contact and quick relief from passing
mechanical splices.
• C-Tips are for mechanically fastened or vulcanized belts. V-Tips are for vulcanized belts only.
• Visual Blade Tension Check: Measure the tension spring and refer to Spring Length Chart on mounting base for
the correct length for best cleaning performance.
• Tensioner: SST Spring Tensioner for self-adjusting tensioning with easy retensioning adjustments.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
MHS HD Secondary with V-Tips*
Product Ordering
Information
MHS
Heavy Duty Secondary Cleaner
(Urethane Cushion Shields, SSTTensioners)
in.
18
24
30
36
42
48
54
60
72
84
96
mm
450 600 750 900 1050 1200 1350 1500 1800 2100 2400
C-Tips or V-Tips
Required
3
4
5
6
7
8
9
10
12
14
16
Urethane Cushion Shield
P R O D U C T H A N D B O O K
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
MHS-24RU 79738 125.8
30
750
MHS-30RU 79739 131.0
36
900
MHS-36RU 79740 141.8
42
1050 MHS-42RU 79741 152.5
48
1200 MHS-48RU 79742 163.3
54
1350 MHS-54RU 79743 174.0
60
1500 MHS-60RU 79744 184.8
72
1800 MHS-72RU 79745 211.9
84
2100 MHS-84RU 79746 247.2
96
2400 MHS-96RU 79747 282.5
Lead time: 1 working day
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
18
450 MHS-18RUV 79748 120.6
24
600 MHS-24RUV 79749 125.8
30
750 MHS-30RUV 79750 131.0
36
900 MHS-36RUV 79751 141.8
42
1050 MHS-42RUV 79752 152.5
48
1200 MHS-48RUV 79753 163.3
54
1350 MHS-54RUV 79754 174.0
60
1500 MHS-60RUV 79755 184.8
72
1800 MHS-72RUV 79756 211.9
84
2100 MHS-84RUV 79757 247.3
96
2400 MHS-96RUV 79758 282.7
*NOTE: V-Tips can be used ONLY on vulcanized belts.
Lead time: 1 working day
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
ICT6
74535 0.7
RSA150
73628 1.3
Lead time: 1 working day
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
UPFCC
79320
.3
Lead time: 1 working day
