87 / 206
www.flexco.com
• phone: 1-630-971-0150
87
U.S. Patent No. 6,823,983; 7,093,706
MHS HD Secondary with C-Tips
Replacement Tips
Tips Required Per Cleaner Size
Product Notes:
• Heavy-duty design to deliver maximum cleaning efficiency on the most demanding, abusive beltlines.
• Pole Length: Belt width plus 54" (1350mm). For longer requirements, see Mineline Installation Accessories - Pole
Extender Kit (page 123).
• Patented PowerFlex
™
cushion design to maintain continuous blade-to-belt contact and quick relief from passing
mechanical splices.
• C-Tips are for mechanically fastened or vulcanized belts. V-Tips are for vulcanized belts only.
• Visual Blade Tension Check: Measure the tension spring and refer to Spring Length Chart on mounting base for
the correct length for best cleaning performance.
• Tensioner: SST Spring Tensioner for self-adjusting tensioning with easy retensioning adjustments.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
MHS HD Secondary with V-Tips*
Product Ordering
Information
MHS
Heavy Duty Secondary Cleaner
(SSTTensioners)
in.
18
24
30
36
42
48
54
60
72
84
96
mm
450 600 750 900 1050 1200 1350 1500 1800 2100 2400
C-Tips or V-Tips
Required
3
4
5
6
7
8
9
10
12
14
16
P R O D U C T H A N D B O O K
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
24
600
MHS-24
75910 124.6
30
750
MHS-30
75911 129.5
36
900
MHS-36
75912 140.0
42
1050
MHS-42
75913 150.4
48
1200
MHS-48
75914 160.9
54
1350
MHS-54
75915 171.3
60
1500
MHS-60
75916 181.8
72
1800
MHS-72
75917 208.3
84
2100
MHS-84
76803 243.0
96
2400
MHS-96
79043 277.7
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
18
450
MHS-18V 76169 119.7
24
600
MHS-24V 76170 124.6
30
750
MHS-30V 76171 129.5
36
900
MHS-36V 76172 140.0
42
1050
MHS-42V 76173 150.4
48
1200
MHS-48V 76174 160.9
54
1350
MHS-54V 76175 171.3
60
1500
MHS-60V 76176 181.8
72
1800
MHS-72V 76177 208.3
84
2100
MHS-84V 76804 243.1
96
2400
MHS-96V 79044 277.9
*NOTE: V-Tips can be used ONLY on vulcanized belts.
Lead time: 1 working day
Lead time: 1 working day
Lead time: 1 working day
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
ICT6
74535 0.7
RSA150
73628 1.3
