• phone: 1-630-971-0150 48
Product Notes:
• Recommended for heavy-duty conveyor applications.
• Material Path Option: Fit the blade width to the belt’s material path. The material path is typically the center 2/3 of the
belt width. In most cases a blade size of belt width minus 6" (150mm) may be the best solution.
• Each cleaner pole is retrofittable for four blade sizes (belt width minus 6" (150mm), minus 12" (300mm), minus 18"
(450mm) or minus 24” (600mm)).
• Pole Length: Belt width plus 54" (1350mm). For longer requirements see Installation Accessories - Pole Extender Kit
(page 123).
• Check tension from regulator in control box. Adjust according to air tension per blade width for optimal tensioning.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
Product Ordering
Information
MHP
MineTough Heavy-Duty Precleaner
with Portable AirTensioner (PAT)
PAT Control Box
U.S. Patent No. D482,508S
Tank sold separately.
See page 49 for options.
P R O D U C T H A N D B O O K
Belt Width Minus 18" (450mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS in. mm in. mm
36 900 18 450 MHP-1836P 78618 266.8
42 1050 24 600 MHP-1842P 78619 284.9
48 1200 30 750 MHP-1848P 78620 303.1
54 1350 36 900 MHP-1854P 78621 321.4
60 1500 42 1050 MHP-1860P 78622 339.6
72 1800 54 1350 MHP-1872P 78623 376.0
84 2100 66 1650 MHP-1884P 78624 412.5
96 2400 78 1950 MHP-1896P 78625 449.0
Belt Width Minus 24" (600mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS in. mm in. mm
42 1050 18 450 MHP-2442P 78676 275.3
48 1200 24 600 MHP-2448P 78677 293.5
54 1350 30 750 MHP-2454P 78678 311.7
60 1500 36 900 MHP-2460P 78679 330.0
72 1800 48 1200 MHP-2472P 78680 366.4
84 2100 60 1500 MHP-2484P 78681 402.9
96 2400 72 1800 MHP-2496P 78682 439.3
Belt Width Minus 6" (150mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS in. mm in. mm
24 600 18 450 MHP-624P 78599 249.6
30 750 24 600 MHP-630P 78600 267.8
36 900 30 750 MHP-636P 78601 286.0
42 1050 36 900 MHP-642P 78602 304.2
48 1200 42 1050 MHP-648P 78603 322.4
54 1350 48 1200 MHP-654P 78604 340.6
60 1500 54 1350 MHP-660P 78605 358.8
72 1800 66 1650 MHP-672P 78606 395.3
84 2100 78 1950 MHP-684P 78607 431.8
96 2400 90 2250 MHP-696P 78608 468.3
Belt Width Minus 12" (300mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS in. mm in. mm
30 750 18 450 MHP-1230P 78609 258.2
36 900 24 600 MHP-1236P 78610 276.4
42 1050 30 750 MHP-1242P 78611 294.5
48 1200 36 900 MHP-1248P 78612 312.8
54 1350 42 1050 MHP-1254P 78613 331.0
60 1500 48 1200 MHP-1260P 78614 349.2
72 1800 60 1500 MHP-1272P 78615 385.7
84 2100 72 1800 MHP-1284P 78616 422.1
96 2400 84 2100 MHP-1296P 78617 458.5
Lead time: 1 working day
