U.S. Patent No. D482,508S
Product Notes:
• Recommended for heavy-duty conveyor applications.
• Material Path Option: Fit the blade width to the belt’s material path. The material path is typically the center 2/3 of the belt width.
In most cases a blade size of belt width minus 6" may be the best solution.
• Each cleaner pole is retrofittable for four blade sizes (belt width - 6", - 12", - 18" or - 24”) (-150mm, -300mm, -450mm, -600mm).
• Pole Length: Belt width plus 54" (1350mm). For longer requirements see Installation Accessories - Pole Extender Kit (page 123).
• Visual Tension Check: No guesswork on blade tensioning. Measure the spring and adjust to specified length per blade width to
restore optimal tensioning.
• To make cleaner installation easier and quicker, see Optional Mounting Kits (page 123).
Product Ordering
Information
MHP
MineTough Heavy-Duty Precleaner
P R O D U C T H A N D B O O K
Belt Width Minus 18" (450mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS
in.
mm in.
mm
36
900
18
450 MHP-1836 78591 266.6
42
1050
24
600 MHP-1842 78592 284.7
48
1200
30
750 MHP-1848 78593 302.9
54
1350
36
900 MHP-1854 78594 321.2
60
1500
42
1050 MHP-1860 78595 339.4
72
1800
54
1350 MHP-1872 78596 377.1
84
2100
66
1650 MHP-1884 78597 413.6
96
2400
78
1950 MHP-1896 78598 450.1
Belt Width Minus 24" (600mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS
in.
mm in.
mm
42 1050 18
450 MHP-2442 78669 275.1
48 1200 24
600 MHP-2448 78670 243.3
54 1350 30
750 MHP-2454 78671 311.5
60 1500 36
900 MHP-2460 78672 329.8
72 1800 48
1200 MHP-2472 78673 367.5
84 2100 60
1500 MHP-2484 78674 404.0
96 2400 72
1800 MHP-2496 78675 440.4
Belt Width Minus 6" (150mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS
in.
mm in.
mm
24
600
18
450
MHP-624 77703 249.4
30
750
24
600
MHP-630 77704 267.6
36
900
30
750
MHP-636 77705 285.8
42
1050
36
900
MHP-642 77706 304.0
48
1200
42
1050 MHP-648 77707 322.2
54
1350
48
1200 MHP-654 77708 341.7
60
1500
54
1350 MHP-660 77709 359.9
72
1800
66
1650 MHP-672 77710 396.4
84
2100
78
1950 MHP-684 77711 432.9
96
2400
90
2250 MHP-696 77712 469.4
Belt Width Minus 12" (300mm)
BELT WIDTH BLADE WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS
in.
mm in.
mm
30
750
18
450
MHP-1230 77713 258.0
36
900
24
600
MHP-1236 77714 276.2
42 1050 30
750
MHP-1242 77715 294.3
48 1200 36
900
MHP-1248 77716 312.6
54 1350 42
1050 MHP-1254 77717 330.8
60 1500 48
1200 MHP-1260 77718 350.3
72 1800 60
1500 MHP-1272 77719 386.8
84 2100 72
1800 MHP-1284 77720 432.2
96 2400 84
2100 MHP-1296 77721 477.6
Lead time: 1 working day
