Replacement
Parts List
MMP
Medium Mine-Duty Precleaner
U.S. Patent No. D482,508S
Spring Tensioner Selection Chart
CLEANER BLADE
WIDTH
76074
QMT-P
76075
QMT-W
76483
QMT-G
79039
QMT-S
TuffShear 18" - 24"
(450 - 600mm)
X
TuffShear 30" - 48"
(750 - 1200mm)
X
TuffShear 54" - 78"
(1350 - 1950mm)
X
TuffShear 84" - 90"
(2100 - 2250mm)
X
6
2
6a
6b
Detail view of Item 4
3
7
7a
4
1
8
5
9
7b
14
10
12
13
11
P R O D U C T H A N D B O O K
Replacement Parts
REF DESCRIPTION
ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
1
24" (600mm) Center Pole
MMPCP24 76458 34.4
30" (750mm) Center Pole
MMPCP30 76459 43.0
36" (900mm) Center Pole
MMPCP36 76460 51.6
42" (1050mm) Center Pole
MMPCP42 76461 60.1
48" (1200mm) Center Pole
MMPCP48 76462 68.7
54" (1350mm) Center Pole
MMPCP54 76463 77.3
60" (1500mm) Center Pole
MMPCP60 76464 85.9
72" (1800mm) Center Pole
MMPCP72 76465 103.1
84" (2100mm) Center Pole
MMPCP84 76808 120.3
96" (2400mm) Center Pole
MMPCP96 77722 137.5
2 Extender Pole Kit
(2 ea.)
MHP-EP 76392 54.0
3 Mounting Plate Kit*
(2 ea.)
MSPMPK 75811 8.3
4 Blade Pin Kit*
(1 ea.)
MMPBPK 76466 0.8
5 Pivot Arm Kit*
(1 ea.)
QMTPAK 76096 4.3
6 Tension Spring - Purple
(1 ea.)
for blades 24" (600mm)
QMTS-P 75845 0.6
6a Tension Spring - White
(1 ea.)
for blades 30" - 90" (750 - 2250mm)
PSTS-W 75898 1.7
6b Tension Spring - Gold
(1 ea.)
for blades 54" - 78" (1350 - 1950mm)
QMTS-G 76484 2.5
6c Tension Spring - Silver
(1 ea.)
for blades 84-90" (2100-2350mm)
PSTS-S 75899 3.0
7 Bushing Kit - Purple
(2 ea.)
QMTBK-P 76097 0.1
7a Bushing Kit - White & Silver
(2 ea.)
QMTBK-W 76098 0.2
7b Bushing Kit - Gold
(2 ea.)
QMTBK-G 76540 0.3
8 Pivot Shaft Bracket Kit*
(1 ea.)
QMTPSBK 76099 4.3
9 Torsion Arm Kit*
(1 ea.)
PSTA 75896 11.4
-
QMT Spring Tensioner* - Purple
(incl. 1 ea. Items 5, 6, 7, 8, & 9)
for blades 18" - 24" (450 - 600mm)
QMT-P 76074 20.4
-
QMT Spring Tensioner* - White
(incl. 1 ea. Items 5, 6a, 7a, 8, & 9)
for blades 30" - 48" (750 - 1200mm)
QMT-W 76075 21.8
-
QMT Spring Tensioner* - Gold
(incl. 1 ea. Items 5, 6b, 7b, 8, & 9)
for blades 54" - 78" (1350 - 1950mm)
QMT-G 76483 23.2
-
QMT Spring Tensioner* - Silver
(incl. 1 ea. Items 5, 6c, 7a, 8 & 9)
blades 84-90 (2100-2350mm)
QMT-S 79039 20.3
10 Air/Water Bag
(1 ea.)
AWTB 75905 3.8
11 Mounting Base
(1ea.)
AWTMB 75906 22.9
12 Torque Arm*
(1 ea.)
AWTA 75907 11.6
13 Hose Kit
(50’ of hose and 6 hose clamps)
AWTHK 75909 6.7
14 PAT Control Box
PACB 78683 11.0
-
PAT Kit- AWT Tensioner w/ Control Box
(includes 2 ea. Items 10,11,12,13 & 1 ea. Item 14)
PAK 78705 86.2
-
AWT Air/Water Tensioner w/o Control
Box
(includes 2 ea. Items 10,11,12 & 13)
AWTNCB 76069 75.2
*Hardware Included
Lead Time: 1 working day
