Replacement
Parts List
PT Max™
BeltTrainer
1 2
3 3a
6
7
8
8a
9a
5
4
9
L1 L2
L3 L3a
L4
P R O D U C T H A N D B O O K
*Hardware included
Lead time: 1 working day
Replacement Parts
REF DESCRIPTION
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm
1 Sensor Roller 2.0* (3" solid roller) (1 ea.) 30-84 750-2100 MSR2 79378 7.0
2 Swivel Mount Kit 2.0* 30-84 750-2100 PMSMK2 79380 5.5
3 Adjusting Arm Kit 2.0* 30-60 750-1500 MAK2 79381 7.9
3a HD Adjusting Arm Kit 2.0* 54-84 1350-2100 MAKHD2 79382 14.7
4 Frame Arm Set Screw Kit HD
(incl. 2 set screws and 2 jam nuts) 30-120 750-3000 MFASKHD 79571 0.8
5 Outer Roller Kit* 30-84 750-2100 MORK 74921 2.6
(incl. 2 rollers, roller thimbles and bolts, nuts and washers)
6 Center Roller Kit* 30-84 750-2100 MCRK 74923 1.2
(incl. 2 rollers, 2 washers, and 2 cotter pins)
7 Center Bearing* 30-84 750-2100 MCB 74925 1.7
8 Center Shaft Spacer Kit (incl. 2 spacers) 30-60 750-1500 MCSK 74927 0.3
8a HD Center Shaft Spacer Kit (incl. 2 spacers) 54-84 1350-2100 MCSKHD 74928 0.5
9 Center Shaft 30-60 750-1500 MCS 74930 4.0
9a HD Center Shaft 54-84 1350-2100 MCSHD 74931 13.0
- Center Bearing Kit (incl. 1 ea. items 5, 6, 7, 8) 30-60 750-1500 MCBK 76025 8.0
- HD Center Bearing Kit (incl. 1 ea. items 5, 6, 7a, 8a) 54-84 1350-2100 MCBKHD 76026 17.0
Legacy Replacement Parts - For PT Max Units Shipped Prior to March 17, 2014
REF DESCRIPTION
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS. in. mm
L1 Sensor Roller* (3" solid roller) (1 ea.) 30-84 750-2100 MSR 74914 7.0
L2 Swivel Mount Kit* 30-84 750-2100 PMSMK 74916 5.5
L3 Adjusting Arm Kit* 30-60 750-1500 MAK 74918 7.9
L3a HD Adjusting Arm Kit* 54-84 1350-2100 MAKHD 74919 14.7
L4 Frame Arm Set Screw Kit
(incl. 2 set screws and 2 jam nuts) 30-120 750-3000 MFASK 75531 0.8
For PT Max Units Shipped
after March 17, 2014 ONLY.
See below for legacy
replacement parts.
*Hardware included
Lead time: 1 working day
Note: All replacement parts offered are common to all three PT Max models: Top Side, Return Side, and V-Return.
