PT Max
™
Top Side
PT Max Return Side
PT Max V-Return
Top of Roller to Bottom of PT Max Minimum Clearance Needed
PT MAX TOP SIDE
BELT TRAINER
(Rollers supplied by end user)
PT MAX RETURN SIDE
BELT TRAINER
(Rollers supplied by end user)
Topside Clearance
Return Side Clearance
V-Return Clearance
Product Ordering
Information
PT Max
™
BeltTrainer
Shaded items are made to order.
Lead time: 15 working days (after
data sheets are approved)
ROLL
DIAMETER
TOPSIDE
RETURN SIDE
V-RETURN
Standard Heavy-Duty Standard Heavy-Duty Standard Heavy-Duty
in.
mm in. mm in.
mm in. mm in.
mm in.
mm in.
mm
5"
127 16" 406 17"
432 17" 432 18"
457 16" 406 17"
432
6"
152 17" 432 18"
457 18" 457 19"
483 17" 432 18'
457
7"
178 18" 457 19"
483 19" 483 20"
508 18" 457 19"
483
PT MAX V-RETURN
BELT TRAINER
(Rollers supplied by end user)
P R O D U C T H A N D B O O K
VERSION
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
Standard
24
600
PTM24T
75583 280.0
30
750
PTM30T
74885 295.0
36
900
PTM36T
74886 310.0
42
1050
PTM42T
74887 325.0
48
1200
PTM48T
74888 340.0
54
1350
PTM54T
74889 355.0
60
1500
PTM60T
74890 370.0
Heavy-
Duty
54
1350 PTMHD54T 74891 390.0
60
1500 PTMHD60T 74892 410.0
72
1800 PTMHD72T 74893 430.0
84
2100 PTMHD84T 74894 450.0
VERSION
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
Standard
24
600
PTM24R 75584 260.0
30
750
PTM30R 74899 275.0
36
900
PTM36R 74900 290.0
42
1050
PTM42R 74901 305.0
48
1200
PTM48R 74902 320.0
54
1350
PTM54R 74903 335.0
60
1500
PTM60R 74904 350.0
Heavy-
Duty
54
1350 PTMHD54R 74905 365.0
60
1500 PTMHD60R 74906 385.0
72
1800 PTMHD72R 74907 405.0
84
2100 PTMHD84R 74908 425.0
VERSION
BELT WIDTH ORDERING
NUMBER
ITEM
CODE
WT.
LBS.
in.
mm
Standard
24
600
PTM24VR 79669
300.0
30
750
PTM30VR 79670
315.0
36
900
PTM36VR 79671
330.0
42
1050
PTM42VR 79672
345.0
48
1200
PTM48VR 79673
360.0
54
1350
PTM54VR 79674
375.0
60
1500
PTM60VR 79675
390.0
Heavy-
Duty
54
1350 PTMHD54VR 79665
410.0
60
1500 PTMHD60VR 79666
430.0
72
1800 PTMHD72VR 79667
450.0
84
2100 PTMHD84VR 79668
470.0
